Protekt CR 240 Series Instruction Manual

it is obligatory to verify the free space required beneath the user at the workplace before each
occasion of use the fall arrest system, so that, in the case of a fall, there will be no collision with the
ground or other obstacle in the fall path. The required value of the free space should be taken from
instruction manual of used equipment.
there are many hazards that may affect the performance of the equipment and corresponding safety
precautions that have to be observed during equipment utilization, especially:- trailing or looping of
lanyards or lifelines over sharp edges,- any defects like cutting, abrasion, corrosion, - climatic
exposure,- pendulum falls,- extremes of temperature,- chemical reagents,- electrical conductivity.
personal protective equipment must be transported in the package (e.g.: bag made of moisture-proof
textile or foil bag or cases made of steel or plastic) to protect it against damage or moisture.
the equipment can be cleaned without causing adverse effect on the materials in the manufacture of
the equipment. For textile products use mild detergents for delicate fabrics, wash by hand or in a
machine and rinse in water. Plastic parts can be cleaned only with water. When the equipment
becomes wet, either from being in use or when due cleaning, it shall be allowed to dry naturally, and
shall be kept away from direct heat. In metallic products some mechanic parts (spring, pin, hinge,
etc.) can be regularly slightly lubricated to ensure better operation.
Other maintenance and cleaning procedures should be adhered to detailed instructions stated in the
manual of the equipment.
personal protective equipment should be stored loosely packed, in a well-ventilated place, protected
from direct light, ultraviolet degradation, damp environment, sharp edges, extreme temperatures and
corrosive or aggressive substances.
IT IS THE RESPONSIBILITY OF THE USER ORGANISATION TO PROVIDE THE IDENTITY CARD AND TO FILL IN THE DETAILS REQUIRED.
THE IDENTITY CARD SHOULD BE FILLED IN ONLY BY A COMPETENT PERSON RESPONSIBLE FOR PROTECTIVE EQUIPMENT. THE
IDENTITY CARD SHOULD BE FILLED IN BEFORE THE FIRST USE OF THE EQUIPMENT. ANY INFORMATION ABOUT THE EQUIPMENT LIKE:
Periodic Inspections, REPAIRS, REASONS OF EQUIPMENT'S WITHDRAWN FROM USE SHALL BE NOTED. THE IDENTITY CARD
SHOULD BE STORAGED DURING A WHOLE PERIOD OF EQUIPMENT UTILIZATION. DO NOT USE THE EQUIPMENT WITHOUT THE

IDENTITY CARD.

IDENTITY CARD
MODEL AND TYPE OF EQUIPMENT
REF. NUMBER
SERIAL NUMBER
USER NAME
DATE OF PURCHASE
PERIODIC EXAMINATION AND REPAIR HISTORY
REASON FOR CONDITION OF DEVICE
DATE
SERVICING/REPAIR
1
2
3
4
5
PROTEKT, 93-403 LODZ,
ul. Starorudzka 9, POLAND,
TEL: (48 42) 680 20 83, FAX: (48 42) 680 20 93
www.protekt.com.pl APAVE SUDEUROPE SAS - BP 193 - 13322 MARSEILLE CEDEX 16 - FRANCE
DATE OF MANUF.
DATE OF FIRST USE
NAME AND SIGNATURE
AFTER SERVICING OF COMPETENT PERSON
Notified body, at which the European certification
was performed and which supervises
the production of the equipment:
Instruction Manual
Read carefully
the manual
before use
the equipment

ESSENTIAL FEATURES

The retractable-type fall arrester device
CR 240 / CR 241 is a component of the
personal protective equipment against falls from
a height and conforms to EN 360:2002.
The fall arrester CR 240 / CR 241 is the
protection for one person only.
Maximum Working Load: 140 kg.
Available lengths of the device:
- Ref. CR 240 06 / CR 241 06 - 6 metres
- Ref. CR 240 10 / CR 241 10 - 10 metres
- Ref. CR 240 12 / CR 241 12 - 12 metres
- Ref. CR 240 15 / CR 241 15 - 15 metres
MARKING OF THE FALL ARRESTER
RETRACTABLE TYPE
FALL ARRESTER
Reference No.:
Cable length:
Serial number:
Date of manufacture:
NEXT
EXAMINATION
DATE
2012
Inspect
the device
before each
use
No. 0082
RETRACTABLE TYPE FALL ARRESTER
Ref. CR 240 xx / CR 241 xx (xx - marking of working length)
CR 240
Top connecting
swivel link
for attaching
the device
to the anchorage
point
type of the equipment
Reference number of the device
CR 240 xx
including the working length of the device
cable length
xx m
serial number of the device
0000001
month and year of manufacture
MM.YYYY
Number and year
of the European Standard
CE mark and number of notified body
inspecting the equipment production
according to the article 11
of Directive 89/686/EEC
device manufacturer or distributor
month and year of the manufacturer's
next inspection
Don't use the device after this date
Attention: Before the first use
mark the date of the first inspection
(date of first use +12 months,
e.g. first use 01.2012 - mark inspection 01.2013)
check locking
before use
before each
read the manual
use
CR 241
Top connecting
connector with swivel
function
for attaching the device
to the anchorage point
Cable retractor
with brake
and energy dissipating
mechanism
inside plastic casing
RETRACTABLE TYPE Identity label RETRACTABLE TYPE
FALL ARRESTER FALL ARRESTER
Reference No.: CR 240 xx Reference No.: CR 240 xx
Cable length: xx m Cable length: xx m
Serial number: 0000001 Serial number: 0000001
Date of manufacture: MM.YYYY Date of manufacture: MM.YYYY
Carrying handle
for transporting
the device
Working cable ø4mm
made of galvanized
steel
Snap hook with swivel function
(Range of alternative hooks
with fall indicator as an option)
range use only a full body
harness conformed
of operating
temperatures to EN 361
maximum don't realese rapidly
working unwinded cable
load
140 kg
don't repair
store the device in
the device
a protected place
yourself
maximal admissible
don't use the device
deflection of the cable
with damaged
from the vertical line
cable
Attach the device Don't use the carrying
to the anchorage handle for attaching
point using the top the device to
swivel link the anchorage point
the device allowed to
+ AZ 800
horizontal usage and
against falls over the edge
