Protekt AT 300 Instruction Manual

anchoring points (equipment) of fall preventive systems should have stable structure and their position should reduce the possibility of falling and
minimise the range of a free fall. The equipment anchoring point should be located above the users work position. The shape and structure of the
equipment anchoring point must provide a durable connection and prevent any random disconnection. It is recommended to use certified and
marked equipment anchoring points in accordance with EN 795.
it is required to inspect the free space under the work-place on which individual fall preventive equipment is going to be used in order to eliminate
the possibility of hitting any objects or lower planes while stopping a fall. The amount of free space under the work-place is specified in the
operational instructions of the protective equipment to be used.
while using the device, pay special attention to hazardous situations which may influence equipment operation and the safety of users, including in
particular:
- kinking and rubbing of lanyards on sharp edges;
- pendulum falls;
- current conductivity;
- any damage such as cuts, wear, corrosion;
- extreme temperature impact;
- negative impact of weather conditions;
- impact of aggressive substances, chemicals, solvents, acids.
personal protective equipment must be transported in packaging which protects it against damage or water, for example in bags made of
impregnated material or in steel or plastic containers or boxes.
personal protective equipment must be cleaned and disinfected in order to avoid damaging the material (raw material) it is made of. Clean textile
materials (slings, lanyards) with cleaning agents intended for soft materials. It can be cleaned manually or washed in machines. It must be carefully
rinsed. Plastic elements can only be cleaned with water. Equipment which becomes wet during cleaning or while in operation must be carefully
dried in natural conditions, away from heat sources. Metal parts and mechanisms (springs, hinges, catches etc.) can be periodically greased in
order to improve their operation.
personal protective equipment should be stored in loose packaging in well-ventilated dry rooms and protected against the impact of light, UV
radiation, dust, sharp objects, extreme temperatures and caustic substances.
The factory where equipment is stored is responsible for making entries in the Operation Sheet. The Operation Sheet should be completed before the
equipment is first put into operation. All information concerning protective equipment (name, serial number, date of purchase and date of putting into
operation, user name, information concerning repairs and inspections and withdrawal from use) must be included in the Operation Sheet of a particular
device. The sheet is completed by the person responsible for safety equipment in a given place of work. Equipment without a properly completed Operation
Sheet cannot be used.
OPERATION SHEET
DEVICE NAME
MODEL
SERIAL
NUMBER
USER
NAME
DATE OF
PURCHASE
TECHNICAL INSPECTIONS
REASONS FOR INSPECTION
DATE OF
INSPECTION OR REPAIR
1
2
3
4
PROTEKT, 93-403 LODZ,
ul. Starorudzka 9, POLAND,
TEL: (48 42) 680 20 83, FAX: (48 42) 680 20 93
www.protekt.com.pl
REFERENCE
NUMBER
DATE OF
MANUFACTURE
DATE OF PUTTING
INTO OPERATION
DATE OF
NOTED DEFECTS, PERFORMED
SUBSEQUENT
REPAIRS, OTHER NOTES
INSPECTION
Notified body, at which the European certification
was performed and which supervises
the production of the equipment:
APAVE SUDEUROPE SAS - BP 193 - 13322 MARSEILLE CEDEX 16 - FRANCE
Instruction Manual
EN 354:2010
The rescue lifting sling AT 300 is a fork lanyard type device.
The AT 300 is designed to be used as a connecting component of personal fall arrest equipement.
BASIC EQUIPMENT
The rescue lifting sling AT 300 is made of polyester webbings, specially sewed to create three attaching points.
The attaching points consist of loops equiped with plastic thimbles.
The AT300 is a symmetrical device.
ATTENTION!
The rescue lifting sling AT 300 can be used only with certified (according to EN 362) connectors.
WORKING LIFE
The AT 300 rescue lifting sling
into use. After a period of 5 years, the AT 300 is to be withdrawn from use and physically destroyed, thus
preventing it from an unintentional reuse. If the AT 300 rescue lifting sling was used to arrest a fall, it has to be
withdrawn from use and physically destroyed. Withdrawal from use should be performed by the person
responsible for safety equipment in a given place of work.
SIGNATURE
OF THE PERSON
CONTENT OF THE RESCUE LIFTING SLING IDENTITY LABEL
RESPONSIBLE
name (type) of the device
reference number
of the device
Ref. AT 300
upper
attaching
point
double
lower
attaching
point
34 cm
can be used for a maximum period of 5 years from the date of first putting it
The CE mark and number of the notified body
responsible for performing the manufacturing process
inspection (art. 11)
read and understand
the manual before use
RESCUE
Date of manufacture:
LIFTING
Serial number:
S L I N G
Length: 90 cm
AT 300
EN 354:2010
Length of the European standard
number of the manufacturing series
device number/year
AT 300
RESCUE
LIFTING
SLING
straining
beam
month/year of manufacture
03.2012
0000001
name of the manufacturer
or distributor
