USE MANUAL
english
CUTTING UNIT
MOD. FP861/A1
ED.1-05/12
SERIAL NUMBER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FP861/A1 and is the answer not in the manual?

Questions and answers

Related Manuals for RASOR FP861/A1

Summary of Contents for RASOR FP861/A1

  • Page 1 USE MANUAL english CUTTING UNIT MOD. FP861/A1 ED.1-05/12 SERIAL NUMBER...
  • Page 2 All the parts of the devices have been planned and produced to guarantee an optimum performance. In order to keep the high quality level and the long reliabilty of the Rasor ® products, it is recommended to use only original spare parts and to contact the head office...

  • Page 3: General Safety Rules

    Do not use large clothes or accessories that might get stuck in the moving parts. • GOGGLES AND PROTECTIVE METAL MESH GLOVES. Always use goggles, protective metal mesh gloves approved by Rasor during use ® and maintenance operations (according to UNI EN 388:2004 standard).
  • Page 4 Elettromeccanica S.r.l. machines have not been conceived to work in areas at risk of ® explosions and at high risk of fire. In case of damage or malfunction, cutting unit FP861/A1 must not be used until the Customer Care Technical Service has repaired them. Customer Care Technical Service For any information, please contact ELETTROMECCANICA S.r.l.

  • Page 5: Transport And Packing

    2. TRANSPORT AND PACKING The cutting unit is delivered in a cardboard box which contains there are various options. The code of the ordered product and its serial number are indicated outside the package (see picture 1). The following accessories are contained in a bag inside the package (see picture HSS steel polygonal blade;...

  • Page 6: Product Description

    4. PRODUCT DESCRIPTION The fixture described in this manual is a pneumatic cutting unit model FP861V which can be assembled on automatic machines (e.g. spreaders, computerized cutting, etc...) by means of a proper bracket. Thanks to a reference pin on the front part and of an effective cutting system with polygonal blade, this cutting unit can be used for many applications: in particular, this cutting unit has been designed to cut hard materials such as moquette, polymeric materials, fiber glass, insulating materials and leather (even...
  • Page 7 6. NOISE LEVEL The maximum acoustic pressure level emitted by cutting unit FP861/A1 is about 60 dB (A). Noise tests have been carried out in compliance with Standard ISO 11202. The device noise levels, measured at different distances (without any sound wave filtering system), vary in the extent of few db (A).

  • Page 8: Use Warnings

    · Always pay attention to the position of the air pipe to prevent it from being cut or damaged by the blade. · It is possible to assemble cutting unit FP861V on machines O.E.M. only if their original structure is not modified. Otherwise, the intervention must be certified by Rasor ® 9. RESIDUAL RISKS Even though the cutting unit is safe, operators must pay attention to preserve their and other people’s safety.

  • Page 9: Installation And Use

    7) Enable the air remotely and carry out the cutting operation. NOTE It is possible to use cutting unit FP861/A1 both keeping it fixed and making the material slide and viceversa. It is important to keep the material to cut as stretched as possible to prevent it from curling...

  • Page 10: Blade Sharpening

    In order to carry out this operation, remove protective plug “A” located on the head of the cutting unit and fill it with Rasor lubricating grease. Screw plug “A” again a few turns. Screw plug “A” a few turns every 2-3 working days (see picture 8).

  • Page 11: Blade Replacement

    5) Replace the worn blade with the new one “2”, being careful to center the blade on the shaft, in the correct position, and remember to assemble it so that the operator can see the writing “Rasor”. 6) Assemble all the components again and sharpen the blade.

  • Page 12: Troubleshooting

    15. TROUBLESHOOTING PROBLEM SOLUTION à Check the counterblade integrity Check the kind of fabric Sharpen the blade The fabric is not cut or it gets stuck between the Check the fabric thickness blade and the counterblade Check the compatibility between blade and fabric Make sure that the turbine turns correctly Reduce the feeding speed Carry out the lubrication...
  • Page 13 ® dal 1946...

  • Page 14: Warranty

    WARRANTY Rasor Elettromeccanica S.r.l. cutting unit has a 12 month warranty from the date indicated ® on the last page of this manual, except in case of different written agreements. The warranty covers all manufacturing and material defects. Replacement and repair operations are covered only if carried out by our company and at our workshop.

  • Page 15: Declaration Of Conformity

    RASOR ELETTROMECCANICA S.R.L. ® 3. Type: FP861/A1 4. Serial number: ................... 5. Year of manufacture: ................. 6. Country of manufacture: ITALY 7. Additional information: ................Date: Warranty expiry: RASOR ELETTROMECCANICA S.R.L. 12 months invoice date or receipt CUTTING EQUIPMENTS (Signature)
  • Page 16 Authorized dealer (Stamp)
