Explorer & Mountaineer - Mirror Replacement Continued
5
A
5. Connect the Signal® mirror mating connector to the Signal® mirror harness and wrap connectors with the supplied foam wrap (A). If heated, re-
connect the heater wires to the heater terminals on the back of the new Signal® mirror (B).
terchanged.
6. Position and align the mirror mount onto the motor actuator. Carefully tuck all wiring behind motor actuator.
ing interfering with mirror travel.
til mirror snaps into place. Firmly press down on all sides of the Signal® mirror to ensure mirror is fully seated and functional.
WARNING: Safety glasses and sturdy gloves are required for mirror replacement.
B
Push all anti-vibration tabs inward so that they are inside of mirror housing. Slowly push down on mirror un-
6
NOTE: There is no polarity so the wires may be in-
Page 6
Not doing so, could result in wir-
