Muth Mirror Systems Signal Installation Instructions Manual page 10

1
A
B
5
Ranger - Door Panel Removal
2
6
3
1. Start with opening the driver's side door and lowering the window..
Remove the screw on the lower left hand corner of door panel using
a Phillips screwdriver (A). Continue removing the (2) screws in the
armrest of door panel [Phillips screwdriver] (B).
2. With a nylon, non-scratchable, pry bar - pry around armrest and un-
snap armrest. Lift up armrest and disconnect all wiring connections.
Remove armrest and set it aside.
3. Using a Phillips screwdriver, remove the screw as shown.
4. Pry around panel cover to disengage it. Remove panel cover.
5. Remove (2) screws on panel plate with a Phillips screwdriver. Re-
move panel plate.
6. Lift up and pull out door panel and set it aside.
Page 10
4
