Ranger - Mirror Replacement Continued
4
4. Position and align the mirror mount onto the motor actuator. Carefully tuck all wiring behind motor actuator.
ing interfering with mirror travel.
ror until mirror snaps into place.
5. Route the Signal® mirror harness around the OE wires as shown .
WARNING: Safety glasses and sturdy gloves are required for mirror replacement.
Push all anti-vibration tabs so that anti-vibration tabs are inside of mirror housing. Slowly push down on mir-
Firmly press down on all sides of the Signal® mirror to ensure mirror is fully seated and functional.
5
Page 13
Not doing so, could result in wir-
