Muth Mirror Systems Signal Installation Instructions Manual page 18

1
USE THE INCLUDED WIRE TAPS AND FOLLOW THE FOUR STEPS ABOVE TO SPLICE INTO THE TURN INDICATOR WIRES
A. Make sure the harnesses are routed securely and enough slack is left for splicing.
B. Splice the BLACK w/ RED TRACE wire from the driver side harness into the wire previously labeled 'driver side indicator'.
C. Splice the BLACK w/ RED TRACE wire from the passenger side harness into the wire previously labeled 'passenger side indicator'.
D. Activate each turn indicator to verify that the Signal
E. Reconnect all original wiring. Turn the ignition power to on, check to verify all features are working properly.
F. Replace the plastic door frame moldings, trim, door panels, and all accessories.
