Muth Mirror Systems Signal Installation Instructions Manual page 17

Please refer to the appropriate model and year, of your vehicle, to get the correct wire color information
2a. The vehicle 's electrical wiri ng is located within the wire bundle along the stee ring column. Locate the left-front: LIGHT GREEN w/ WHITE STRIPE
(left-rear : LIGHT GREEN w/ ORANGE STRIPE - includes brake) wire within the wi re bun dle. Turn the ignition key so th at electrical power i s on
and activate th e driver side turn indicator. Probe the wire with th e wire tester to verify th at flashing turn directional power is present. Label that
wire as 'dr iver side indicator '. Find th e right-front: WHITE w/ LIGHT BLUE STRIPE (right-rear : O RANGE w/ LIGHT BLUE STRIPE - i ncludes
brake). A ctivate th e passenger side turn indicator an d probe the wire with th e wire tester to verify th at flashing turn directional power is present.
Labe l that wire as 'passenger side indicator'.
2
2c. Th e vehicle's electrical wirin g is locate d within the wire bundle alon g the steer ing column. Locate the left-front: BLUE w/ GREEN STRIPE (left-
rear : GRAY w/ BROWN STRIPE - includes brake) wire within the wire bundle. Turn the igniti on key so that electrical power is on and activate the
dr iver side turn indicator. Probe th e wire with the wire tester to ve rify that flashing turn directional power is presen t. Label th at wire as 'dr iver
side indicator'. Find th e right-front: YELLOW w/ VIOLET STRIPE (right-rear: VIOLET w/ O RANGE STRIPE - includes brake ). Activate the pas-
sen ger side turn indicator and probe the wire with th e wire tester to verify that fl ashing tur n dir ection al power is present. Label th at wir e as
'passenger side indicator'.
2006 Ranger & Mazda B-Series
2b. Th e vehicle's electrical wiring is located within the wire bundle alon g th e steering column.
Locate the solid VIOLET w/ WHITE STRIPE wire within the wire bundle. Turn the ignition
key so that electrical power is on and activate the driver side turn indicator. Probe the wi re
with the wire tester to verify that flashing tur n directional power is present. Label that wire
as 'dr iver side indicator' . NOTE: There are (3) violet w/ white stripe wires in this location.
Please verify with wire tester to confirm you have correctly identif ied the correct wire. Lo-
cate the GREY w/ YELLOW STRIPE wire. Acti vate the passen ger side turn indi cator and
probe the wire with the wir e tester to verify that flash ing turn directional power is pr esent.
Labe l that wire as 'passenger side indicator'.
2006-2010 Sportrac, Explorer & Mountaineer
2007-2010 Ranger & Mazda B-Series
(can include brake so probe carefully)
