Summary of Contents for Huawei ECC500

  • Page 1 ECC500 V600R001C03 User Manual Issue Date 2019-12-20 HUAWEI TECHNOLOGIES CO., LTD.
  • Page 2 Notice The purchased products, services and features are stipulated by the contract made between Huawei and the customer. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information, and recommendations in this document are provided "AS IS"...
  • Page 3: About This Document

    About This Document About This Document Purpose This document describes the energy control center 500 (ECC500 for short) in terms of its overview, configurations, ports, installation, commissioning, user interfaces, maintenance, and troubleshooting, providing guidelines for onsite installation personnel and technical support engineers.
  • Page 4  Updated some MDU screenshots. Issue 02 (2018-05-20) Updated section "How Can I Change the ECC500 IP Address on the WebUI?". Updated section "How Should I Link an AI/DI Alarm to a DO Port". Issue 01 (2017-10-28) Added section "How Should I Link an AI/DI Alarm to a DO Port".
  • Page 5: Table Of Contents

    4 Installation and Commissioning ....................28 4.1 Installation and Commissioning Flowchart ........................ 28 4.2 Installing Devices ............................... 28 4.2.1 Installing a Rack-mounted ECC500 ........................28 4.2.2 Installing a Wall-mounted ECC500 ......................... 30 4.2.3 (Optional) Installing a Rack-mounted Independent Deployment AI/DI Unit ............30 4.2.4 (Optional) Installing a Wall-mounted Independent Deployment AI/DI Unit ............
  • Page 6 7 FAQ ..............................66 7.1 ECC500 Device Cascading Rules ..........................66 7.2 What Can I Do If the ECC500 Collector Cannot Be Logged In on the WebUI? ............66 7.3 How Can I Install a Network Security Certificate? ....................67 Issue 04 (2019-12-20) Copyright ©...
  • Page 7 7.15 How Can I Set Temperature and Humidity Alarm Thresholds for a T/H Sensor? ............ 81 7.16 How Can I Change Fan Alarm Thresholds and Reset a Fan? ................... 82 7.17 How Can I Delete a Device Failing in Communication or Restart the ECC500? ............. 84 7.18 How Can I View Performance Data? ........................85 7.19 How Can I View Operation Logs? ..........................
  • Page 8: Safety Information

    The "NOTICE", "WARNING", and "DANGER" statements in this document do not cover all the safety instructions. They are only supplements to the safety instructions. Huawei will not be liable for any consequence caused by the violation of general safety requirements or design, production, and usage safety standards.
  • Page 9  Keep irrelevant people away from the equipment. Only operators are allowed to access the equipment.  Use insulated tools or tools with insulated handles, as shown in the following figure. Issue 04 (2019-12-20) Copyright © Huawei Technologies Co., Ltd.
  • Page 10  To avoid electric shock, do not connect safety extra-low voltage (SELV) circuits to telecommunication network voltage (TNV) circuits. Issue 04 (2019-12-20) Copyright © Huawei Technologies Co., Ltd.
  • Page 11: Personnel Requirements

    Do not power on the equipment before it is installed or confirmed by professionals. 1.2 Personnel Requirements  Personnel who plan to install or maintain Huawei equipment must receive thorough training, understand all necessary safety precautions, and be able to correctly perform all operations.
  • Page 12 When selecting, connecting, and routing cables, follow local safety regulations and rules. The static electricity generated by human bodies may damage the electrostatic-sensitive components on boards, for example, the large-scale integrated (LSI) circuits. Issue 04 (2019-12-20) Copyright © Huawei Technologies Co., Ltd.
  • Page 13: Installation Environment Requirements

     Ensure that the equipment room provides good heat insulation, and the walls and floor are dampproof.  Install a rat guard at the door of the equipment room. Issue 04 (2019-12-20) Copyright © Huawei Technologies Co., Ltd.
  • Page 14: Mechanical Safety

    Before hoisting objects, ensure that hoisting tools are firmly secured onto a load-bearing object or wall.  Ensure that the angle formed by two hoisting cables is no more than 90 degrees, as shown in the following figure. Issue 04 (2019-12-20) Copyright © Huawei Technologies Co., Ltd.
  • Page 15 Do not climb higher than the fourth rung of the ladder from the top.  Ensure that your body's center of gravity does not shift outside the legs of the ladder. Issue 04 (2019-12-20) Copyright © Huawei Technologies Co., Ltd.
  • Page 16: Others

    Metal shavings from drilling may short-circuit boards inside the equipment.  Obtain the consent from the customer, subcontractor, and Huawei before drilling.  Wear goggles and protective gloves when drilling holes. ...
  • Page 17 UPS output voltage level or frequency. Doing so may affect the power supply to equipment.  Exercise caution when setting battery parameters. Incorrect settings will affect the power supply and battery lifespan. Issue 04 (2019-12-20) Copyright © Huawei Technologies Co., Ltd.
  • Page 18: Overview

    2.2 Features Hardware Functions  The ECC500 supports AC inputs of 100 V to 240 V, 50 Hz or 60 Hz, and can be used worldwide.  RS485 Communication Card, AI/DI Expansion Card and independent deployment AI/DI unit support only RJ45 terminals, minimizing cable types, simplifying delivery, and enabling fast deployment.
  • Page 19: Typical Application Scenarios

    The ECC500 supports the automatic assess of sensors such as water sensors and NTC resistor-based temperature sensors, simplifying delivery and deployment.  The ECC500 provides the 12 V DC power supply to devices such as sensors and audible and visual alarms. Additional power supply to these devices is not needed. ...
  • Page 20 Local Management If the ECC500 is used for local management, there is no need to configure the NMS and the ECC500 works as a data collector and manager. The ECC500 collects, analyzes, and processes device data, while users manage the devices on the ECC500 WebUI.
  • Page 21 User Manual 2 Overview Figure 2-3 Networking for local management For the devices that can be connected to and managed by the ECC500 used for local management, see Devices Managed by the ECC500. Issue 04 (2019-12-20) Copyright © Huawei Technologies Co., Ltd.
  • Page 22: Configurations And Port

    3 Configurations and Port Configurations and Port 3.1 Configurations The ECC500 consists of a power module, a main control module, an RS485 expansion card, and an AI/DI expansion card. The detailed configuration rules are as follows:  An ECC500 with standard configurations consists of a main control module, a power...
  • Page 23 ECC500 User Manual 3 Configurations and Port Table 3-1 ECC500 component functions Hardware Silk Screen Configuration Function Main control SMU03A Mandatory (1 PCS)  Provides an LCD to module query, set, and control local parameters.  Provides an operating status indicator and alarm indicator.
  • Page 24: Port

    3.2.1 Main Control Module The main control module provides the LCD for querying, setting, and controlling local parameters. Figure 3-2 shows ports on the front panel of the main control board. Issue 04 (2019-12-20) Copyright © Huawei Technologies Co., Ltd.
  • Page 25 A critical or major alarm is generated. LCD/Buttons The LCD displays parameters that for you to configure and query in real time by pressing the four buttons on the panel. Table 3-3 describes the buttons. Issue 04 (2019-12-20) Copyright © Huawei Technologies Co., Ltd.
  • Page 26: Power Module

    RS485 interfaces for connecting southbound equipment; reserved. COM2 Reserved. This port is protected by a security protection mechanism. 3.2.2 Power Module Figure 3-3 shows the port on the front panel of the power module. Issue 04 (2019-12-20) Copyright © Huawei Technologies Co., Ltd.
  • Page 27: Rs485 Communication Card

    Structure The subrack of the power module is less than 1 U high and occupies two slots of the ECC500 subrack. 3.2.3 RS485 Communication Card The RS485 communication card provides five half-duplex RS485 communication interfaces that are compatible with two-wire and four-wire cables and connect to the southbound intelligent equipment, Independent Deployment AI/DI Unit, and intelligent ambient temperature and humidity sensor.
  • Page 28 12 V DC output. COM5/12V The port provides no 12 V DC output. Table 3-7 describes ports on the front panel of the RS485 communication card. Issue 04 (2019-12-20) Copyright © Huawei Technologies Co., Ltd.
  • Page 29 The internal circuit design of the RS485 communication card allows its COM port to support two-wire RS485 and four-wire RS422, eliminating the need to cascade cables, as shown in Figure 3-5. Issue 04 (2019-12-20) Copyright © Huawei Technologies Co., Ltd.
  • Page 30: Ai/Di Expansion Card

    Figure 3-6 Front panel of the AI/DI expansion card (1) DO control (2) AI/DI_1 (3) AI/DI_2 (4) AI/DI_3 (5) AI/DI_4 (6) Indicators Table 3-8 describes indicators on the front panel of the AI/DI expansion card. Issue 04 (2019-12-20) Copyright © Huawei Technologies Co., Ltd.
  • Page 31 AI/DI_2, 20 mA current signals, signals from current-based smoke sensors and AI/DI_3, and water sensors, dry contact signals, and NTC signals. AI/DI_4 Pin definition:  3: 12 V DC, 54 mA Issue 04 (2019-12-20) Copyright © Huawei Technologies Co., Ltd.
  • Page 32: Independent Deployment Ai/Di Unit

    14.6 V, 54 mA output power. 3.2.5 Independent Deployment AI/DI Unit When the AI/DI expansion card installed in the ECC500 has insufficient space for AI/DI data collection, you can connect an Independent Deployment AI/DI Unit to the AI/DI expansion card using an RS485 bus. The eight AI/DI input ports on the module can collect more AI/DI signals.
  • Page 33 20 mA current signals, signals from current-based smoke sensors and water sensors, dry contact signals, and NTC signals. Pin definition:  3: 12 V DC, 54 mA  6: D-  7: D+  8: GND Issue 04 (2019-12-20) Copyright © Huawei Technologies Co., Ltd.
  • Page 34 50 m), set toggle switch 4 to ON for the furthest independent deployment AI_DI unit. After the DIP switch settings are modified, power off and restart the independent deployment AI_DI unit for the new settings to take effect. Issue 04 (2019-12-20) Copyright © Huawei Technologies Co., Ltd.
  • Page 35: Installation And Commissioning

    User Manual 4 Installation and Commissioning Installation and Commissioning 4.1 Installation and Commissioning Flowchart Figure 4-1 shows the flowchart for installing and commissioning the ECC500. Figure 4-1 ECC500 installation and commissioning flowchart 4.2 Installing Devices 4.2.1 Installing a Rack-mounted ECC500 Prerequisites ...
  • Page 36 Ensure that the floating nuts on both sides are on the same horizontal line. Step 2 Place the ECC500 on the correct guide rails in the cabinet. Step 3 Secure the ECC500 in the cabinet by tightening the M6 screws clockwise on the right and left mounting ears, as shown by (2) in Figure 4-3.
  • Page 37: Installing A Wall-Mounted Ecc500

    Step 3 Drill holes at the marked installation position (hole spacing: 52 mm x 472 mm) on the wall using a hammer drill, and install four M8 expansion bolts into the holes. Step 4 Install the ECC500 at the expansion bolts on the wall and ensure that the rear panel of the ECC500 is flush with the wall.
  • Page 38 Step 3 Secure the Independent Deployment AI/DI Unit in the cabinet by tightening the M6 screws clockwise on the right and left mounting ears, as shown in Figure 4-6. Figure 4-6 Installing a rack-mounted Independent Deployment AI/DI Unit ----End Issue 04 (2019-12-20) Copyright © Huawei Technologies Co., Ltd.
  • Page 39: Optional) Installing A Wall-Mounted Independent Deployment Ai/Di Unit

    4.3 Connecting Cables 4.3.1 Connecting Ground Cables After an ECC500 or an Independent Deployment AI/DI Unit is installed, connect a ground cable to it and connect the other end of the ground cable to the cabinet or site ground point.
  • Page 40: Connecting To An Ip Network

    ECC500 and an IP network. Figure 4-9 Connecting to an IP network 4.3.3 Connecting Monitoring Cables All AI/DI and RS485 ports on expansion cards of the ECC500 are connected to monitoring components using standard Ethernet cables with RJ45 connectors, as shown in Figure 4-10.
  • Page 41: Connecting Power Cables

    Figure 4-10 Connecting monitoring cables Connect an audible and visual alarm to the ECC500 using the delivered adapter. 4.3.4 Connecting Power Cables The power module of the ECC500 is connected to the external power supply using a power cable. Figure 4-11 shows the cable connection.
  • Page 42: Commissioning The Ecc500

    4 Installation and Commissioning Figure 4-11 Connecting a power cable (1) ECC500 power port 4.4 Commissioning the ECC500 Commission the ECC500. For details, see ECC500 V600R001C03 Hardware Cable Connection and Commissioning Guide. Issue 04 (2019-12-20) Copyright © Huawei Technologies Co., Ltd.
  • Page 43: Ui Description

    ECC500 User Manual 5 UI Description UI Description 5.1 LCD The LCD of the ECC500 is located on the front panel of the main control module. It allows you to:  View active alarms.  View the running status of the system.
  • Page 44: Lcd Operations

    LCD. For details about buttons on the front panel of the main control module, see LCD/Buttons.  The figure is for reference only. Selecting a Language After powering on the ECC500, select English by pressing , as shown in Figure 5-2, and then press to enter the standby screen.
  • Page 45: Webui

    If the ECC northbound interface is connected by a NetEco, devices connected to the COM port on the ECC500 do not need to be added on the ECC WebUI, such as the UPS, temperature and humidity sensor, NetCol, PDU8000, and ATS.
  • Page 46: Commissioning Preparations

    To ensure access Changeme security, change the password upon first login. For details, 7.7 How Can I Change the ECC500 WebUI Password?. Remember the new password because it is necessary for ECC500 Issue 04 (2019-12-20) Copyright © Huawei Technologies Co., Ltd.
  • Page 47: Adding A Networked Device

    You have obtained the ECC500 IP address as well as the user name and password for WebUI login.  You have prepared a PC which is in the same IP address segment as the ECC500 and connected the PC to the ECC500 over a switch. Context Networked devices, such as ATMs, are devices with the same IP attributes in an equipment room or site.
  • Page 48 User Manual 5 UI Description Procedure Step 1 On a PC which is in the same IP address segment as the ECC500, enter https://XX.XX.XX.XX in the address box, and press Enter. XX.XX.XX.XX indicates the ECC500 IP address. Step 2 (Optional) Install a network security certificate if a certificate problem message is displayed.
  • Page 49: Optional) Adding A Video Link

    You have obtained the ECC500 IP address as well as the user name and password for WebUI login.  You have prepared a PC which is in the same IP address segment as the ECC500 and connected the PC to the ECC500 over a switch. Context ...
  • Page 50 Step 5 Select the video link to be submitted, and click Submit. Step 6 Click View in Video Info List to display the linked camera page. Figure 5-10 Viewing camera information ----End Issue 04 (2019-12-20) Copyright © Huawei Technologies Co., Ltd.
  • Page 51: Optional) Setting Snmp Monitoring Parameters

    You have obtained the ECC500 IP address as well as the user name and password for WebUI login.  You have prepared a PC which is in the same IP address segment as the ECC500 and connected the PC to the ECC500 over a switch. Context ...
  • Page 52 Step 9 Set Trap Target Address to the NetEco server IP address, Trap Port to the user-defined port number, and SNMP Version to the required version. Step 10 After setting the parameters, click Confirm. Issue 04 (2019-12-20) Copyright © Huawei Technologies Co., Ltd.
  • Page 53: Optional) Setting The Security Certificates For The Ecc500 Collector And The Network Management System

    You have obtained the ECC500 IP address as well as the user name and password for WebUI login.  You have prepared a PC which is in the same IP address segment as the ECC500 and connected the PC to the ECC500 over a switch. ...
  • Page 54 ----End Follow-up Procedure Import the NMS security certificate and key issued by an authorized party into the upper-level NMS of the ECC500 collector. Then the ECC500 collector will be able to communicate with the network management system. Issue 04 (2019-12-20)
  • Page 55: Optional) Changing The Challenge Certification Password

    5.2.6 (Optional) Changing the Challenge Certification Password Prerequisites  You have obtained the IP address of the ECC500 collector as well as the user name and password used for WebUI login.  You have prepared a PC which is in the same IP address segment as the ECC500 and connected the PC to the ECC500 over a switch.
  • Page 56 Save the current configuration file to the PC. Step 4 Import a configuration file. Log in to the WebUI of the ECC500 to which a configuration file is to be imported. Choose Maintenance > Configuration File. Click Browse, specify the path where the configuration file is stored in the PC, and click Upload.
  • Page 57: Optional) Viewing The Real-Time Surveillance Screen, Active Alarms, Historical Alarms, And Historical Data

    You have obtained the ECC500 IP address as well as the user name and password for WebUI login.  You have prepared a PC which is in the same IP address segment as the ECC500 and connected the PC to the ECC500 over a switch. Procedure Step 1 Log in to the ECC500 WebUI.
  • Page 58: Maintenance And Troubleshooting

    The ALM indicator is off. 6.2 Alarm Reference This section describes the alarm reference and troubleshooting methods for the ECC500 in the NetEco. All alarm IDs in this document are the alarm IDs allocated by the NetEco. Issue 04 (2019-12-20)
  • Page 59: Alarm Reference For The Rs485 Communication Card

    ----End Clearing This alarm is cleared when the board is securely inserted into the subrack and the communication between the board and the ECC500 resumes. 6.2.1.2 MUS02A_COM4 Voltage Low Alarm Description This alarm is generated when the output voltage of the COM4 port is below the alarm threshold.
  • Page 60: Alarm Reference For The Ai/Di Expansion Card

    AI/DI_1 port on the AI/DI expansion card. 6.2.2.1 MUE05A_Board Not Exist Description This alarm is generated when the board is not securely inserted or is faulty. Issue 04 (2019-12-20) Copyright © Huawei Technologies Co., Ltd.
  • Page 61: Mue05A_Aidi_1 Di Alarm

    ----End Clearing This alarm is cleared when the board is securely inserted into the subrack and the communication between the board and the ECC500 resumes. 6.2.2.2 MUE05A_AIDI_1 DI Alarm Description This alarm is generated when the normally open (NO) dry contacts are closed or the normally closed (NC) dry contacts are open.
  • Page 62: Mue05A_Aidi_1 Sensor Fault

    The sensors are faulty. Procedure Step 1 Check whether onsite signal volumes exceed the allowed ranges. Step 2 Check that sensor cables are properly connected. Step 3 Replace the faulty sensors. ----End Issue 04 (2019-12-20) Copyright © Huawei Technologies Co., Ltd.
  • Page 63: Mue05A_Aidi_1 Over Alarm

    This alarm is cleared when the values reported by the sensors are within the allowed ranges. 6.2.2.5 MUE05A_AIDI_1 Lower Alarm Description This alarm is generated when the values reported by the sensors are below the lower alarm thresholds. Issue 04 (2019-12-20) Copyright © Huawei Technologies Co., Ltd.
  • Page 64: Mue05A_Aidi_1 Voltage Low Alarm

    Alarm ID Alarm Severity Alarm Type 22651 Set to Major by default. Equipment alarm Impact on the System After this alarm is generated, the equipment keeps running, but sensors may be affected. Issue 04 (2019-12-20) Copyright © Huawei Technologies Co., Ltd.
  • Page 65: Mue05A_Aidi_1 Sensor Connection Error Alarm

    Step 2 Check that the sensor types on the WebUI match the actual sensor types. ----End Clearing This alarm is cleared when the types of sensors detected by AIDI_1 match the specified types and sensor cables are correctly connected. Issue 04 (2019-12-20) Copyright © Huawei Technologies Co., Ltd.
  • Page 66: Alarm Reference For The Independent Deployment Ai/Di Unit

    Step 2 Rectify faults in the power supply. Step 3 Replace the faulty board. ----End Clearing This alarm is cleared when the board is properly connected and the communication between the board and the ECC500 resumes. Issue 04 (2019-12-20) Copyright © Huawei Technologies Co., Ltd.
  • Page 67: Mue06A_Power Voltage Low Alarm

    ----End Clearing This alarm is cleared when the power voltage exceeds the alarm clearance threshold. 6.2.4 Comm Failed Description This alarm is generated when a networked device is disconnected from the ECC500. Attribute Alarm ID Alarm Severity Alarm Type Critical...
  • Page 68: Network Device Connect Fail

     The ECC500 communications board is faulty.  The device is faulty. Procedure Step 1 Check whether the communications cable between the ECC500 and the device is disconnected.  If yes, reconnect the communications cable.  If no, go to Step Step 2 Check whether the ECC500 communications board is faulty.
  • Page 69: Ecc500 Network Fault

    User Manual 6 Maintenance and Troubleshooting  The networked device is faulty. Procedure Step 1 Check whether the communications cable between the ECC500 and the networked device is disconnected.  If yes, reconnect the communications cable.  If no, go to Step Step 2 Check whether the parameters are correctly set for the networked device.
  • Page 70: Troubleshooting

    ECC500 User Manual 6 Maintenance and Troubleshooting Procedure Step 1 Check whether the communications cable between the ECC500 and the switch is disconnected.  If yes, reconnect the communications cable.  If no, go to Step Step 2 Check whether the ECC500 is faulty.
  • Page 71: Parts Replacement

    Context This section describes how to replace parts of the ECC500.  Before replacing parts, ensure that the power supply to the ECC500 has been disconnected and power cable terminals have been removed.  Only trained and qualified personnel are allowed to perform the operations.
  • Page 72 6-1. Figure 6-1 Removing an old module Step 4 Grasp the handle of the new module and put the module into the correct slot in the ECC500 subrack. Step 5 Push the new module into the subrack until their front panels are aligned with each other.
  • Page 73: Faq

    You have obtained the ECC500 IP address as well as the user name and password for WebUI login.  You have prepared a PC which is in the same IP address segment as the ECC500 and connected the PC to the ECC500 over a switch. Context Use Internet Explorer 8 as an example.
  • Page 74: How Can I Install A Network Security Certificate

    You have obtained the ECC500 IP address as well as the user name and password for WebUI login.  You have prepared a PC which is in the same IP address segment as the ECC500 and connected the PC to the ECC500 over a switch. ...
  • Page 75: How Can I Change The Ecc500 Ip Address On The Lui

    You have obtained the IP address, subnet mask, and default gateway information planned for the ECC500. Context A unified IP address (192.168.1.168) is configured for all ECC500s before delivery. Reconfigure an IP address for the ECC500 as required to ensure normal communication with a server. Procedure Step 1 Press on the ECC500 LUI.
  • Page 76: How Can I Change The Ecc500 Ip Address On The Webui

    Procedure Step 1 On a PC which is in the same IP address segment as the ECC500, enter https://192.168.1.168 in the address box, and press Enter on the keyboard. Step 2 (Optional) Install a network security certificate if a certificate problem message is displayed.
  • Page 77 7-3. Figure 7-3 ECC500 login page Step 4 Choose System Settings > IP Address Settings. Change the IP address, subnet mask, and default gateway for the ECC500 based on the planned parameters, as shown in Figure 7-4. Issue 04 (2019-12-20)
  • Page 78: How Can I Change The Ecc500 Lui Password

    Step 4 Press to move the cursor to Change Password and press Remember the new password because it is necessary for ECC500 commissioning and maintenance. Step 5 Press to change the value and press to confirm.
  • Page 79: How Can I Change The Ecc500 Webui Password

    7.7 How Can I Change the ECC500 WebUI Password? Prerequisites  You have prepared a PC which is in the same IP address segment as the ECC500 and connected the PC to the ECC500 over a switch.  You have obtained the ECC500 IP address as well as the user name and password for WebUI login.
  • Page 80: How Can I Create A User

    You have obtained the ECC500 IP address as well as the user name and password for WebUI login.  You have prepared a PC which is in the same IP address segment as the ECC500 and connected the PC to the ECC500 over a switch. Context The Administrator, Engineer, and Operator user groups are optional on the user management page, and they have different operation rights.
  • Page 81 ECC500 User Manual 7 FAQ Procedure Step 1 Log in to the ECC500 WebUI as an administrator. Step 2 Choose Maintenance > User Management. Step 3 Click Add, as shown in Figure 7-7. Figure 7-7 Adding an ECC500 user _01...
  • Page 82: How Can I Set The Date And Time

    You have obtained the ECC500 IP address as well as the user name and password for WebUI login.  You have prepared a PC which is in the same IP address segment as the ECC500 and connected the PC to the ECC500 over a switch. Procedure Step 1 Log in to the ECC500 WebUI.
  • Page 83: How Can I Handle Alarms

    You have obtained the ECC500 IP address as well as the user name and password for WebUI login.  You have prepared a PC which is in the same IP address segment as the ECC500 and connected the PC to the ECC500 over a switch. Procedure Step 1 Log in to the ECC500 WebUI.
  • Page 84: How Should I Link An Ai/Di Alarm To A Do Port

    This section describes how to link the alarm generated from the AI/DI_1 port on the MUE05A expansion card to the SLOT1_DO port. Procedure Step 1 Log in to the ECC500 WebUI. Step 2 Choose Monitoring > MUE05A Expansion Card > MUE05A4 > Running Parameter > AI/DI_1 Port Settings.
  • Page 85 Submit.  SLOT1_DO (new page) or DO1 (old page) represents that the MUE05A expansion card where the DO port is located is installed in slot 1 of the ECC500.  DO_1 represents the DO_1 port on the GPRS expansion card.
  • Page 86: How Can I Change The System Site Name

    You have obtained the ECC500 IP address as well as the user name and password for WebUI login.  You have prepared a PC which is in the same IP address segment as the ECC500 and connected the PC to the ECC500 over a switch. Context Site network fault alarms are sent to the specified mobile phone numbers of maintenance engineers through SMS.
  • Page 87: How Can I Change The Device Name

    You have obtained the ECC500 IP address as well as the user name and password for WebUI login.  You have prepared a PC which is in the same IP address segment as the ECC500 and connected the PC to the ECC500 over a switch. Context ...
  • Page 88: How Can I Set Temperature And Humidity Alarm Thresholds For A T/H Sensor

    You have obtained the ECC500 IP address as well as the user name and password for WebUI login.  You have prepared a PC which is in the same IP address segment as the ECC500 and connected the PC to the ECC500 over a switch. Procedure Step 1 Log in to the ECC500 WebUI.
  • Page 89: How Can I Change Fan Alarm Thresholds And Reset A Fan

    You have obtained the ECC500 IP address as well as the user name and password for WebUI login.  You have prepared a PC which is in the same IP address segment as the ECC500 and connected the PC to the ECC500 over a switch. Context A fan can be automatically identified.
  • Page 90 The following describes how to modify parameters, using fan 1 as an example. Procedure Step 1 Log in to the ECC500 WebUI. Step 2 Choose Monitoring > FAN Group > FAN1 > Running Parameter. Modify High Temperature Alarm Thres and Low Temperature Alarm Thres.
  • Page 91: How Can I Delete A Device Failing In Communication Or Restart The Ecc500

    You have obtained the ECC500 IP address as well as the user name and password for WebUI login.  You have prepared a PC which is in the same IP address segment as the ECC500 and connected the PC to the ECC500 over a switch. Context ...
  • Page 92: How Can I View Performance Data

    You have obtained the ECC500 IP address as well as the user name and password for WebUI login.  You have prepared a PC which is in the same IP address segment as the ECC500 and connected the PC to the ECC500 over a switch. Procedure Step 1 Log in to the ECC500 WebUI.
  • Page 93: How Can I View Operation Logs

    You have obtained the ECC500 IP address as well as the user name and password for WebUI login.  You have prepared a PC which is in the same IP address segment as the ECC500 and connected the PC to the ECC500 over a switch. Procedure Step 1 Log in to the ECC500 WebUI.
  • Page 94: How Can I Export Data

    You have obtained the ECC500 IP address as well as the user name and password for WebUI login.  You have prepared a PC which is in the same IP address segment as the ECC500 and connected the PC to the ECC500 over a switch. Procedure Step 1 Log in to the ECC500 WebUI.
  • Page 95: How Can I Restore Factory Settings

    User Manual 7 FAQ  You have prepared a PC which is in the same IP address segment as the ECC500 and connected the PC to the ECC500 over a switch. Procedure Step 1 Log in to the ECC500 WebUI.
  • Page 96 System Site Name in System Settings > Site Settings  Video Info List parameters in Maintenance > View Video Procedure Step 1 Log in to the ECC500 WebUI. Step 2 Choose Maintenance > Configuration File and click Restore Factory Settings, as shown in Figure 7-25.
  • Page 97: A Technical Specifications

    ECC500 User Manual A Technical Specifications Technical Specifications Table A-1 describes the technical specifications of the ECC500. Technical specifications of the ECC500#d0e10516 Category Item Specifications –20° C to +65° C Environmental Operating temperature requirements –40° C to +70° C Storage temperature Humidity 5%–95% RH (non-condensing)
  • Page 98 The monitoring module certification components and PCB comply with regulatory requirements of the IEC60950-1 or EN60950-1. Mechanical Dimensions (H x W x D) 44.5 mm x 175 mm x 100 mm specifications Issue 04 (2019-12-20) Copyright © Huawei Technologies Co., Ltd.
  • Page 99: B Devices Managed By The Ecc500

    ECC500 User Manual B Devices Managed by the ECC500 Devices Managed by the ECC500 Table B-1 lists the devices managed on the ECC500 WebUI. Device list#table_01 Device Type Port Type Device Software Device Model Version UPS2000-G RS485 UPS2000-G-A:  V100R001C10 ...
  • Page 100 Dry contact Audible and visual alarm  a: If the version used onsite is not ACC V100R001C30, contact Huawei technical support.  b: If the version used onsite is not ACC V100R001C20SPC500, contact Huawei technical support. Issue 04 (2019-12-20) Copyright © Huawei Technologies Co., Ltd.
  • Page 101: C Acronyms And Abbreviations

    C Acronyms and Abbreviations Acronyms and Abbreviations analog input Automatic Transfer Switch digital input digital output Energy Control Center Fast Ethernet Internet Protocol Liquid Crystal Display LCD user interface Management Information Base Issue 04 (2019-12-20) Copyright © Huawei Technologies Co., Ltd.
  • Page 102 ECC500 User Manual C Acronyms and Abbreviations power distribution unit SNMP Simple Network Management Protocol uninterruptible power system Issue 04 (2019-12-20) Copyright © Huawei Technologies Co., Ltd.
