Connection

6.1

Notes on preventing damage

Only touch connector pins and wires if you are suitably earthed to pre-
vent damage to the sensor due to electrostatic discharge.
6.2

Core assignment

Type of connection K
Flying lead
Core colour code:
BK black, BE beige, BN brown, BU blue, GN green, GY grey, OG orange, PK pink,
RD red, VT violet, WH white, YE yellow
GEL 2800
Notes on preventing damage
Core
GN A+
YE A–
OG CLOCK+
BE CLOCK–
PK Preset
BU GND
RD U
B
BK B+
VT B–
BN DATA+
WH DATA–
GR Error
Signal / function
Incremental signal track A
Inverse incremental signal track
A
Input: Differential clock signal in
accordance with RS 485
Input: Differential clock signal in
accordance with RS 485
Set measuring range zero point
Weight
Supply voltage
Incremental signal track B
Inverse incremental signal track
B
Output: Differential data signal
in accordance with RS 485
Output: Differential data signal
in accordance with RS 485
Error output, insulate core if not
used
