Vortex Razor HD 4000 User Manual page 2

RAZOR HD 4000 SPECIFICATIONS
®
DEER RANGE
1,600 yd.
NORMAL MODE
(1,463 m)
NORMAL MODE 2,000 yd.
(SCAN) (1,829 m)
2,200 yd.
ELR MODE
(2,012 m)
*Expected ranges given favorable environmental conditions
Minimum Range: 5 yd. (4 m)
Accuracy: ± 0.5 yards at 5-199.9 yards
± 1 yards at 200-1,000 yards
± 2 yards at over 1,000 yards
Maximum Angle Reading: ± 70 degrees
Measuring Time: < .25 seconds (Normal Mode)
Battery Life: > 4,000 range cycles
Operating Temperature: -4° to 140° F (-20° to 60° C)
Storage Temperature: -13° to 140° F (-25° to 60° C)
Magnification: 7x
Objective Lens: 25 mm
Eye Relief: 16-19 mm
Diopter: ± 2
Brightness Settings: 5
Battery: CR2
Weight: 9.9 oz.
Length: 114mm
Width: 34mm
TREE RANGE REFLECTIVE RANGE
1,800 yd. 2,400 yd.
(1,646 m) (2,194 m)
2,200 yd. 2,400 yd.
(2,012 m) (2,194 m)
2,500 yd. 4,000 yd.
(2,286 m) (3,658 m)
*Cold weather may reduce battery performance
2
RAZOR HD 4000 LASER RANGEFINDER
®
The Razor HD 4000 is the essential companion for the
®
extreme hunter, archer and shooter. The extremely effective
angle compensated laser rangefinder features four targeting
modes (Normal Mode, First Mode, Last Mode and Extended
Laser Range Mode) for any ranging environment. The
primary HCD (Horizontal Component Distance) range mode
provides key angle compensated range information required
by the vast majority of shooters in a simple, quick to read
display. The Razor HD 4000 also has a LOS (Line of Sight)
range mode and scan feature.
Images are for representation only. Product may vary slightly from what is shown.
3
