Summary of Contents for M Design RD 750
- Page 1 COLLECTION RD 750,1000 INSTRUCTION FOR INSTALLATION AND USE...
-
Page 2: Table Of Contents
GENERAL RECOMMENDATIONS ....................... 8 ............................. 9 AINTANCE 4.1.1 Cleaning glass ............................ 9 SECURITY CONDITIONS ..........................9 SUPPLIED ACCESORIES ........................... 10 SIGN ............................... 11 TECHNICAL DRAWINGS RD 750......................12 TECHNICAL DRAWINGS RD 1000 ......................13 ………...........................14 GUARANTEE 10.1 ITEMS COVERED ........................14 ERMS AND 10.2 ........................... -
Page 3: General
GENERAL TRANSPORT AND INSTALLATION The LUNA RD is transported in a horizontal position or if there are some problems – in angle-wise °. To make transport easier you can use a set of transport holders. The transport holders fix to the correct position behind the set screws of the stove. /Pic.1/. ... -
Page 4: Optimal Operation
1.2.1.1 Optimal operation Optimal use of fuel and optimal operation of the stove reach loading cca.3,5kg of the wood per hour (3pieces cca.50cm long), lying horizontal on the raft in the middle of the combustion room. The chimney effect 12-15Pa and the regulator supply air open 30%. 1.2.2 Forbidden fuel The use of treated wood /painted, etc./ and all types of household waste, which can disperse hazardous... -
Page 5: List Of Standards To Be Observed During Assembly And Operarions
must be positioned so as to maintain the safety distance from any flammable materials that could not fire. However, if you decide to carry out the work on your own, we advise you to do the following: Refer to the terms and conditions of our contract of guarantee ... -
Page 6: Installation The Fireplace Model Series „Rd" On The Place Of Use
this area is necessary to ensure sufficient fresh air. INSTALLATION THE FIREPLACE MODEL SERIES „RD“ ON THE PLACE OF USE Fireplace type series "LUNA HC" is installed in the heated or outside of heated space. For the location of the fireplace insert type series "RD" in the heated space, the operator must decide whether to implement the distribution of heated air or not. -
Page 7: Ventilation
VENTILATION 2.9.1 Natural convection Fireplace should be located at least 20 mm above the floor / when it is placed on the floor / so as to permit from bottom of the natural inlet of air. For sufficient circulation of heated air must be ensured that surround has hole from the bottom with at least 4dm , excluding dust filter, or if including filter 6dm 2.9.2... -
Page 8: Chimney
2.10 CHIMNEY The design of the chimney must deal with strict conditions: • The chimney must be insulated. • One stack may have more than two changes of direction. The angle of this change of direction must be greater than 30 ° - 45 ° from the vertical direction. •... -
Page 9: General Recommendations
GENERAL RECOMMENDATIONS The device must be connected and tested before there is done the surround. To make sure the equipment is working optimally. Do not place flammable materials in close distance of the fireplace stove. Note: If you leave the door open, a small piece of burning wood / carbon / may fall to the floor. Insulation materials: it is preferable to use high temperature resistant materials. -
Page 10: Security Conditions
SECURITY CONDITIONS In operating the fireplace stove type series "RD" is necessary to observe the following precautions: The fireplace furnace type series "RD" can use only an adult. At a distance of 1000 mm in front of the fireplace stove type series "RD" do not place flammable objects and materials. -
Page 11: Sign
Pic.15 the appliance is designed for: short-term operation serial number /see Pic.15/ TYPE- fireplace stove RD RD 750 RD 1000 Rated thermal power (kW) 14,7 15,7 Average efficiency (%) -
Page 12: Technical Drawings Rd 750
750 RD... -
Page 13: Technical Drawings Rd 1000
1000 RD... -
Page 14: Guarantee
10. GUARANTEE This page is your warranty card. The guarantee is only valid for faults caused by construction defects or defects in the parts used to build the appliance 10.1. TERMS AND ITEMS COVERED - 8 years` guarantee on the general structure - 2 years` guarantee on the parts - No guarantee on glass, seals and lining the combustion chamber 10.2.
