Camera Mount System
THANK YOU
Thank you for purchasing a C5CM-128 Camera Mount. Please read these instructions thoroughly
before installing this product.
PRODUCT FEATURES
• Convenient system securely mounts a camera at the bottom, middle, or top of screens of the C5
Large Format Monitor Mounting System.
• Weight rated to 10 lbs. of maximum capacity.
Instruction Sheet
C5CM-128
I-00773
Rev A
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Middle Atlantic Products C5CM-128
Summary of Contents for Middle Atlantic Products C5CM-128
- Page 1 Camera Mount System C5CM-128 THANK YOU Thank you for purchasing a C5CM-128 Camera Mount. Please read these instructions thoroughly before installing this product. PRODUCT FEATURES • Convenient system securely mounts a camera at the bottom, middle, or top of screens of the C5 Large Format Monitor Mounting System.
- Page 2 IMPORTANT SAFETY INSTRU CTIONS / INSTRUCTIONS IMPORTAANTES SUR LA SÉCURITÉ WARNING! Middle Atlantic Products, Inc. electrical AVERTISSEMENT! Middle Atlantic Products, Inc. systems conform to and should be properly grounded in électrique systèmes conformes à devraient être mis à la compliance with requirements of the current National terre dans conformité...
- Page 3 SUPPLIED HARDWARE (10x) M4 x 10 (10x) Drop-In (2x) M6 x 12 Phil. M4 T-nuts Hex Screws Head Screws (5x) 10-32 Hex 10-32 x 1/2 Phil. (2x) End (4x) End Cap Flange Nuts Head Screw Caps Plugs REQUIRED TOOLS • 2.5 mm Hex Key •...
- Page 4 INSTALLING THE CAMERA MOUNTING BRACKET REINFORCEMENT (IF APPLICABLE) NOTE: Only install the bracket reinforcement when you attach the camera mounting bracket in the top or bottom positions on the support beam. M6 x 12 Phil. head screws 1. Use to attach the bracket reinforcement with the narrow tip toward where the stem of the bracket will be as shown.
- Page 5 INSTALLING THE CAMERA MOUNTING BRACKET REINFORCEMENT (CONTINUED) 10-32 x 1/2 Phil. head 2. Use the screw and a 10-32 hex flange nut to attach the tip of the bracket reinforcement to the stem of the camera mount. (FIGURE D) Bracket reinforcement Bracket reinforcement in bottom position.
- Page 6 ATTACHING CAMERA MOUNTING PLATES TO THE CAMERA BRACKET (CONTINUED) 2. Use a 3/8 wrench to secure (4x) 10-32 hex flange nuts on the bolts of the camera mounting plate to attach it to the camera mounting bracket in your desired position. (FIGURE F) FIGURE F NOTE: Refer to your camera’s documentation for specific mounting instructions before attempting to mount the camera to the bracket or plate.
- Page 7 ATTACHING BRACKETS TO THE UNIVERSAL PLATE (CONTINUED) 2. Horizontally slip the T-nuts into the universal plate channels and further tighten the screws to secure your desired horizontal position along the universal plate. (FIGURE H) NOTE: You may need to loosen the screws later in order to make minor adjustments. Universal Plate FIGURE H ADJUSTING THE SUPPORT BEAM (IF NECESSARY)
- Page 8 Voice: 613-836-2501 - Fax: 613-836-2690 / ca.middleatlantic.com - customerservicecanada@middleatlantic.ca Factory Distribution USA: NJ - CA - IL Canada: ON - BC At Middle Atlantic Products we are always listening. Your comments are welcome. Middle Atlantic Products is an ISO 9001 and ISO 14001 Registered Company. Page 8...
