OPERATION MANUAL
Model TMM5 PLUS-X Series
Multi-Purpose Tilt Chair and Surgi-Chair II
Options:
W
T
L
F
E
B
A
5516 S.W. 1
Phone: 1-800-237-3377 - Fax: 1-352-854-9544
www.transmotionmedical.com
Wide
Tall
Low
Folding Footrest
Export
Battery
AC Power
st
Lane – Ocala, FL 34474
Page 1 of 30
Document No.: TMM-2220-13
Revision: A
