1,2,3 Step Friendly Installation
The Enforcer control panel has numerous design features that allow for a quick and easy
installation:
1. Fix the back casing to the wall.
2. Wire the mains cable to the mains terminal connectors and connect
the telephone line if Digi 1200 is used or connect Digi GSM.
3. Ready to program.
220V
Mains Input
PSU unit location
Rear Wall
Tamper
Hinged Front
Panel
Front Tamper
2.2 Amp
Back up battery
Two digital
communicators
available:
DIGI-1200
Fast PSTN Digital
communicator
DIGI-GSM
GSM Digital
communicator
2 wired inputs,
3 programmable outputs,
RS485 bus interface
RS232 connection for
local programming
via UDL software
