Description; Handle Subassembly; Foam Grip; Snap Link - CYBEX 55620 G Owner's And Service Manual

ITEM QTY PART NO.
1 1 01048
2 1 01069
3 2 JC780422
4 6 JS388300
5 4 HN784000
6 1 4000M218
7 1 PP080202
8 1 01054
9 4 GP000004
10 2 GP000203
11 2 GP000000
12 4 HC700414
13 1 JC782838
14 1
15 1 01055
16 4 01066
17 2 01755
18 2 5310M035
19 2 PR060005
20 2 JC782830
21 2 PP080204
22 2 01239
23 4 PN660201
24 1 4700M005
25 1 4700-010
• 26
• 27 19 4005C062
28 1 HP286819
29 2 JC700917
30 4 JC700922
• 31 2 4700-019
• 32 2 BR030206
33 1 JC782834
34
35 1 02106
36 1 HS308300
37 1 JC620415
38 1 4800-024
39 2 4800-071
40 1 01065
41 1 4000Y316
42 1 02521
43
44 1 4800-381
45 1 01063
46 1 5310P044
47 1 C-ZA000200
48 1 02224
• FOR UNITS MANUFACTURED PRIOR TO JUNE 1993, CALL 1-888-462-9239.
1. Keep all shipping packages near area of installation. Standard items incude:
• Lat Column Assembly - 5601-98
• Lat Pulldown Package - 5601-50
• Lat Pulldown Cushion Box Assembly - 4005A070-0
NOTE: x denotes specific color
2. When installing seat support, tip 90 degrees and insert through column slot. NOTE: Remove lower cross braces
(if installed) before installing seat support. Use hardware supplied with the Center Post to secure seat
support to lower cross braces.
3. Securely tighten seat support before installing weight stack.
4. Follow the assembly guidelines listed on either the 5600 Modular Center Post Assembly & Parts instruction sheet
or the 5629 Tandem Center Post Assembly & Parts instruction sheet.
5601 - Lat Pulldown

DESCRIPTION

Seat Support
Adjusting Post
BHSCS .50-13 x 1.50
Split Lockwasher .50
Hex Nut .50-13
Detent Pin
Plastic Insert
Pulley Mount
Pulley Spacer
Pulley Center
Pulley Assembly
BHCS .375-16 x .62
SHCS .50-13 x 3.50
Plastic Insert
Scuff Plate
Plastic Fastener
Guide Rod Collet
Weight Stack Guide Rod
Weight Bumper
SHCS .50-13 x 2.50
Plastic Cap .625 ID x .68 OD
Spacer
Hole Plug
Rubber Cap
Top Weight Assembly
Removed
Stack Weight 4 x 12
Spiral Pin
FHSCS .375-16 x 1.00
FHSCS .375-16 x 1.50
Flange Bearing
Retaining Ring
SHCS .50-13 x 3.00
Removed
Half Weight Peg
Split Lockwasher .25
BHSCS .25-20 x .75

Seat Cushion

Thigh Cushion
Placard Decal
Caution Decal
Warning Decal
Removed
General Warning Decal
Cable Subassembly
Weight Selector Pin
Half Weight
Modular Screen (not shown)
Assembly Notes
ITEM QTY PART NO.
49 1 01255
50 2 GQ000206
51 1 4005-105
52 1 3900-426
53 1 4800-515
54 2 4800-101
55 2 5310M042
56 2 PR400201
57 2 HS760106
58 1 BS070201
59 1 PP460200
• Top Weight Package - 4700-010 (black)
• Weight Pack 1 - 4700S040 (black)
• Weight Pack 2 - 4700S043 (black)
DESCRIPTION

Handle Subassembly

Snap Link

Pulldown Bar (not shown)
Vortex Decal
Weight Plate Decal
Wear Cover

Foam Grip

Foam Grip (not shown)
Flat Washer 1.75 .69 .14T
Com Spring .56 x .66 x 1.50 LG
Plastic Knob
