- Page 1 Summit SD-1150-WP ™ Wheelchair Scale Version 11439 Operation Manual October 2, 2019 PN 197294...
- Page 2 All information contained within this publication is, to the best of our knowledge, complete and accurate at the time of publication. Rice Lake Weighing Systems reserves the right to make changes to the technology, features, specifications and design of the equipment without notice.
-
Page 3: Table Of Contents
7.0 Warranty ................20 Technical training seminars are available through Rice Lake Weighing Systems. - Page 4 Summit SD-1150-WP Wheelchair Scale Rice Lake continually offers web-based video training on a growing selection of product-related topics at no cost. Visit www.ricelake.com/webinars www.RiceLake.com Visit our website...
-
Page 5: Introduction
The Summit SD-1150-WP Wheelchair Scale is a heavy-duty scale that offers exceptional performance measuring 36'' x 36'' (0.91 m x 0.91 m) and has a capacity of up to 1000 lb (500 kg). The Summit SD-1150-WP Wheelchair Scale is designed to be mounted in a pit flush with the floor. -
Page 6: Installation
10' length of load cell cable. The Summit SD-1150-WP Wheelchair Scale has one threaded hole located in the center of the deck to allow for the installation of an eyebolt. An eyebolt hook and chains can be used to lift the scale. It is recommended to use a 1/2''-20NF eyebolt for lifting the scale. -
Page 7: Assembly
6. Pull out excess and tighten the cord grip to hold the cable snugly. Indicator Terminal Location Figure 2-2. Junction Box Wiring Cable Color Code Junction Box White Green Black +SIG -SIG Table 2-1. Titanium 10-Button Indicator Junction Box Connections © Rice Lake Weighing Systems ● All Rights Reserved... -
Page 8: Pit Installation
Figure 2-4. Pit Frame Diagram A 1:24 slope is recommended for the pit with full grouting under the corner pads. Load Cell Foot Assembly 1:24 Slope Figure 2-5. Installed Summit SD-1150-WP and Pit Frame Section www.RiceLake.com Visit our website... -
Page 9: Load Cell Connections
Do not over tighten the zip tie which holds the load cell wire in place or internal components may be damaged. IMPORTANT 4. Reinstall the rounded back cover and attach to the tilt stand. © Rice Lake Weighing Systems ● All Rights Reserved... -
Page 10: Power The Scale
Summit SD-1150-WP Wheelchair Scale Power the Scale The Summit SD-1150-WP Wheelchair Scale may be powered with six AA batteries or by using an optional AC adapter. 2.8.1 Battery Power The six AA batteries that come with the scale offer an average of 25 hours of continuous use. -
Page 11: Optional Power Connections
Installation 2.8.2 Optional Power Connections Rice Lake Weighing Systems offers optional AC adapters to use when power is available. Rice Lake Weighing Systems offers replacement AC adapters. Using an unauthorized power supply voids all IMPORTANT warranties. USB Connection AC Power Connection Figure 2-11. -
Page 12: Operation
Summit SD-1150-WP Wheelchair Scale Operation The following section provides operation instructions for the Summit SD-1150-WP Wheelchair Scale. Figure 3-1. Indicator Front Panel Item No. Function Allows the user to access the BMI (Body Mass Index) function; This key only works if there is a locked weight shown on the display;... -
Page 13: Powering The Scale
4. Have subject step on the scale with the accessory items. Weight displays and the NET annunciator remains on. The weight of the additional items remain stored in memory. To cancel the tare weight, press TARE © Rice Lake Weighing Systems ● All Rights Reserved... -
Page 14: Set Units
Summit SD-1150-WP Wheelchair Scale Set Units Press to toggle from kg to lb, display unit desired for weights. Weigh Mode Have subject to be weighed step onto the scale. The weight value displays. When the weight is stable, the LOCK annunciator displays and an audible tone indicates the end of the weighing process. -
Page 15: Communications
The indicator comes with an RS-232 port which enables weight data to be transmitted to other equipment, such as a computer or printer. The RS-232 cable with DB-9 connector (PN 100719) is available from Rice Lake Weighing Systems. Figure 4-3 on page 14 shows where the RS-232 connection is located on the indicator. -
Page 16: Escape Protocol
Summit SD-1150-WP Wheelchair Scale Escape Protocol The escape protocol uses the escape (0X1B or ASCII 27) to indicate that a command is following. On the PC side there must be a software listener created by the vendor that will interpret this protocol. This listener must also take care of all the issues regarding data integrity and other information to ensure the data sent and received is valid. -
Page 17: Maintenance Protocol
Firmware ID and development version Current weight Current AD Zero the scale Show flash values (used for the first flash process) USB On/Off (not available on USB communication Table 4-4. Maintenance Protocol Commands © Rice Lake Weighing Systems ● All Rights Reserved... -
Page 18: Usb Connection
Basic information on USB driver installation using Windows is described in the following steps and serves only as an example. A USB driver can be downloaded from the Rice Lake Weighing Systems website at: https://www.ricelake.com/resources/software-firmware 1. Select Software. - Page 19 6. Select Install the software automatically then select Next. A file transfer screen displays as the file downloads and installs to the computer. 7. Select Finish when the completion screen displays. © Rice Lake Weighing Systems ● All Rights Reserved...
- Page 20 Summit SD-1150-WP Wheelchair Scale 8. To verify the installation, the driver can be viewed in the device manager of the computer. Figure 4-8. Device Manager 9. To configure a printer using the USB driver, open the software driver Parpar in the device manager (Figure 4-8).
-
Page 21: Maintenance And Troubleshooting
Maintenance and Troubleshooting Maintenance and Troubleshooting The following section provides maintenance and cleaning instructions for the Summit SD-1150-WP Wheelchair Scale. Do not immerse the scale in cleaning or other liquid solutions. IMPORTANT Do not use Isopropyl alcohol or other solutions to clean the indicator display surface. - Page 22 Summit SD-1150-WP Wheelchair Scale www.RiceLake.com Visit our website...
-
Page 23: Specifications
230 VAC-9 VDC-50 Hz Battery Type AA Alkaline Battery Use 25 hours of continuous use Environmental Operating Temperature 50±104°F (14–40°C) Storage Temperature 32–158°F (0–70°C) Humidity 85% relative humidity Certifications and Approvals RoHS Compliant © Rice Lake Weighing Systems ● All Rights Reserved... -
Page 24: Warranty
Summit SD-1150-WP Wheelchair Scale Warranty Rice Lake Weighing Systems (RLWS) warrants that all RLWS equipment and systems properly installed by a Distributor or Original Equipment Manufacturer (OEM) will operate per written specifications as confirmed by the Distributor/OEM and accepted by RLWS. All systems and components are warranted against defects in materials and workmanship for two years. - Page 26 Specifications subject to change without notice. Rice Lake Weighing Systems is an ISO 9001 registered company. 230 W. Coleman St. • Rice Lake, WI 54868 • USA U.S. 800-472-6703 • Canada/Mexico 800-321-6703 • International 715-234-9171 • Europe +31 (0)26 472 1319...
