- Page 1 Survivor RT ® Pit-Type Track Scale Installation Manual To be the best by every measure ™ 110876...
-
Page 3: Table Of Contents
3.6 Electrical Ground Connections ........... . 6 Diagrams ............................9 Survivor RT Limited Warranty ........................ 14 © 2009 Rice Lake Weighing Systems. All rights reserved. Printed in the United States of America. Specifications subject to change without notice. June 2009... - Page 4 Survivor® RT Installation Manual...
-
Page 5: About This Manual
400,000 lb specs. RT-6610 66 x 10’ 400,000 lb RT-7010 70’ x 10’ 400,000 lb RT-7210 72’ x 10’ 400,000 lb RT-7510 75’ x 10’ 400,000 lb RT-8010 80’ x 10’ 400,000 lb Table 1-1. Survivor RT Series Platform Sizes Introduction... -
Page 6: Installation
Installation ® This section describes the assembly procedure for the railroad track scale. Survivor Weighbridge Installation 1. Set load cell lower base plates in place on 4. Set module wooden blocking embedded anchors and place necessary foundation. (Place lateral check rods through components for each cell at cell location. - Page 7 Figure 2-6. Module in place 7. Adjust load cell base plate leveling bolts to proper height and level plates. Figure 2-7. Load cell base plate adjusting to proper height 8. Continue this process at each section, moving down the scale. 9.
-
Page 8: Rail Installation
Rail Installation ® The following instructions describe the installation of rail sections on the Survivor ° 1. Cut rail sections using 45 mitered rail head cuts at the weighrail and approach rail transitions. Mitered rail head cuts location Figure 2-9. 2. -
Page 9: Concrete Deck
Concrete Deck 1. Install deck pan. Figure 2-10. Deck pan installed 2. Set manhole frames in desired locations and shim to proper height. Figure 2-11. Manhole frame 3. Install rebar and pour concrete. After the concrete hardens, cut deck pan from within manhole frame. Figure 2-12. -
Page 10: Junction Box And Grounding
Junction Box and Grounding Cable installation instructions for the weigh module(s) are included in the following paragraphs: Load Cells to Junction Box Junction Box Connections Each load cell is equipped with 30' of load cell cable, Each junction box is large enough to hold the sufficient to reach a centrally-located junction box on summing board, transient protection devices, standard scales. - Page 11 Therefore, the best grounding system for the scale is These, and all, ground connections must be torqued to the same grounding system used for the incoming AC a specified value and retorqued at regular service power system. The 120 VAC power source used to intervals.
- Page 12 186210 TRIM TRIM EXPANSION/J9 TRIM TRIM EXPANSION/J9 Assembly Assembly PN Rev. PN Rev. +SEN +SEN -SEN -SEN JP10 JP10 INDICATOR/J10 INDICATOR/J10 TRIM TRIM TRIM TRIM TRIM TRIM TRIM TRIM +SEN +SEN JP17 JP12 JP17 JP12 -SEN -SEN JP18 JP13 JP18 JP13 CUT TRACE TO ISOLATE SENSE LINE CUT TRACE TO ISOLATE SENSE LINE...
-
Page 13: Diagrams
Diagrams Diagrams... - Page 14 ® Survivor Installation Manual...
- Page 15 Diagrams...
- Page 16 ® Survivor Installation Manual...
- Page 17 Diagrams...
-
Page 18: Survivor Rt Limited Warranty
Survivor RT Limited Warranty Rice Lake Weighing Systems (RLWS) warrants that all RLWS equipment and systems properly installed by a Distributor or Original Equipment Manufacturer (OEM) will operate per written specifications as confirmed by the Distributor/OEM and accepted by RLWS. All systems and components are warranted against defects in materials and workmanship for two years.
