- Page 1 Manual iPC-I XC16/PCI Intelligent PC/CAN Interface The expert for industrial and automotive communication...
- Page 2 Internet: www.ixxat.com e-Mail: info@ixxat.de e-Mail: sales@ixxat.com Support In case of unsolvable problems with this product or other IXXAT products please contact IXXAT in written form by: Fax: +49 (0)7 51 / 5 61 46-29 e-Mail: support@ixxat.de For customers from the USA/Canada Fax: +1-603-471-0880 e-Mail: techsupport@ixxat.com...
-
Page 3: Table Of Contents
5.3 Note on disposal of used devices ........10 5.4 Technical specifications ............. 12 5.5 Accessories ................ 13 CAN bus terminal resistor ..............13 5.6 FCC Compliance ..............13 5.7 EC Declaration of Conformity ........... 14 Copyright IXXAT Automation GmbH iPC-I XC16/PCI - Manual, V1.3... -
Page 5: Introduction
The IXXAT PC-CAN interface iPC-I XC16/PCI is a powerful electronic component, developed and manufactured in accordance with the latest technological stand- ards. This manual is intended to familiarize you with your iPC-I XC16/PCI inter- face. Please read this manual before beginning with installation. -
Page 6: Installation
For installation of the VCI driver under Windows, please refer to the VCI installa- tion manual. 2.2 Hardware installation Before inserting the iPC-I XC16/PCI in the PCI slot, you should install the software driver (see previous section). For all work on the PC and interface, you must be statically discharged. Work must be carried out on an earthed, anti-static work mat. - Page 7 CAN-low (fault tolerant), (only automotive version) CAN-low CAN-high (fault tolerant), (only automotive version) Not connected Not connected CAN-high Not connected Not connected Table 3-1: Pin assignment of the CAN bus connection Copyright IXXAT Automation GmbH iPC-I XC16/PCI - Manual, V1.3...
-
Page 8: Pci Bus Connection
The assignment of the PCI connector is designed in accordance with the PCI spec- ification 2.2. The iPC-I XC16/PCI can be operated both in a 3.3V and in a 5V PCI signal environment. The maximum PCI bus frequency with which the interface can be operated is 33MHz. -
Page 9: Firmware Update
CANopen Master API, BCI etc.) or an update of the UCI firmware becomes necessary, you can download the necessary files and tools in the download sec- tion of our website. Copyright IXXAT Automation GmbH iPC-I XC16/PCI - Manual, V1.3... -
Page 10: Appendix
Based on the B2B regulation, disposal is governed separately in the Terms of Sale of IXXAT in accordance with § 10 para. 2 clause 3 of the Electrical and Electronic Equipment Act (ElektroG) in the version of 16.03.2005. - Page 11 The Terms of Sale and their supplements as well as further information on the disposal of used devices can be downloaded from www.ixxat.com. Copyright IXXAT Automation GmbH iPC-I XC16/PCI - Manual, V1.3...
-
Page 12: Technical Specifications
Storage temperature range: -40°C .. +85°C Relative humidity: 10 - 95%, non-condensing Galvanic isolation: 1000V DC between CAN bus and internal logic Device safety: CSA/UL 60950-00 Class 3862 10, 3862 90 Copyright IXXAT Automation GmbH iPCI-I XC16/PCI - Manual, V1.3... -
Page 13: Accessories
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Copyright IXXAT Automation GmbH iPC-I XC16/PCI - Manual, V1.3... -
Page 14: Ec Declaration Of Conformity
Appendix 5.7 EC Declaration of Conformity IXXAT Automation hereby declares that the product: iPC-I XC16/PCI with the article numbers: 1.01.0047.33260 1.01.0047.33110 1.01.0047.33220 do comply with the EC directives 2004/108/EC. Applied harmonized standards in particular: EN 55022:2006 + A1:2007 EN 55024:1998 + A1:2001 + A2:2003 22.08.11, Dipl.-Ing.
