RF Elements CC Series Manual page 3

Asymmetrical horn antenna

Advertisement

Asymmetrical Horn CC
Package Contents for: HG3-CC-A20 Antenna
To continue installation see Step 1
4
Number Description
www.rfelements.com
1
5
1
AH-CC Body
2
AH-CC Bracket Base
3
AH-CC Bracket Arm
4
AH-CC Bracket
5
M6 x 20mm Screw
6
M8 x 75mm Screw
7
AH-CC Handle
6
Quantity
HG3-CC-A20
2
3
7
1x
1x
1x
1x
6x
2x
1x
