Asymmetrical Horn CC
Overview
20° Horn
HG3-CC-A20
30° Horn
HG3-CC-A30
60° Horn
HG3-CC-A60
90° Horn
HG3-CC-A90
Estimation based on pre-production units. Subject to change.
www.rfelements.com
Product ID
HG3-CC-A20
16.3 x 16.4 x 10.0 inch
HG3-CC-A30
16.3 x 13.7 x 12.8 inch
HG3-CC-A60
18.6 x 13.6 x 10.8 inch
HG3-CC-A90
17.2 x 15.4 x 11.9 inch
ALL HARDWARE STAINLESS STEEL
USE ANTI-SEIZE THREAD LUBRICANT
Dimensions
414 x 417 x 254 mm
414 x 347 x 325 mm
472 x 342 x 275 mm
437 x 391 x 302 mm
Weight Gain (dBi)
6.6 kg
14.6 lbs
6.6 kg
14.6 lbs
6.7 kg
14.8 lbs
7.5 kg
16.5 lbs
20.5
20.5
17.0
16.0
