- Page 1 All manuals and user guides at all-guides.com AUDIO TOYOTA GENUINE AUDIO NOTICE EXPLICATIVE DE L’INSTALLATION Avensis FÜR-FOR-POUR ** T25 * R Binder Volume 4 Manual Ref.no A4RT25/J-0-0...
- Page 2 All manuals and user guides at all-guides.com Avensis (T25) TOYOTA GENUINE AUDIO 1. TABLE OF CONTENTS 1. Application Chart .................................... 2. System Layout ....................................3. In-dash 6 CD-Changer Installation ..............................4. Hide-away 6 CD-changer installation .............................. Avensis (RHD) - 3...
-
Page 3: Application Chart
All manuals and user guides at all-guides.com p. 1/1... -
Page 4: System Layout
All manuals and user guides at all-guides.com Avensis (T25) TOYOTA GENUINE AUDIO 2. SYSTEM LAYOUT THE HIDE-AWAY 6 CD-CHANGER NOTE: The installation position of the hide-away 6 CD-changer in under the driver seat. Avensis (RHD) - 5 10-02... -
Page 5: In-Dash 6 Cd-Changer Installation
All manuals and user guides at all-guides.com Avensis (T25) TOYOTA GENUINE AUDIO 3. IN-DASH 6 CD-CHANGER INSTALLATION Remove the shift knob and shift cover using a nylon pry tool. : Clip (4x) : Nail (4x) Fig. 1 Remove the panel : Clip (5x) Fig. - Page 6 All manuals and user guides at all-guides.com Avensis (T25) TOYOTA GENUINE AUDIO Remove the audio unit : Bolt (4x) Fig. 4 Remove the glove compartment a) Remove the hooks : Hook (2x) b) Remove the stoppers by pulling them inside.
- Page 7 All manuals and user guides at all-guides.com Avensis (T25) TOYOTA GENUINE AUDIO Cut the tape into 10 equal pieces. Fig. 7 Relocate the vehicle connector position from location “A” to location“B” and attach the connector to the har- ness using tape...
- Page 8 All manuals and user guides at all-guides.com Avensis (T25) TOYOTA GENUINE AUDIO Route and attach the changer wire using wire ties : Wire tie (3x) Wire of changer unit Connect Fig. 9 10. Route the changer wire using wire ties...
- Page 9 All manuals and user guides at all-guides.com Avensis (T25) TOYOTA GENUINE AUDIO 11. Cut the template (312N) (see page 22, 23) using scissors. Fig. 11 12. Mark the dashboard using the template Hole fit (312N) Corner fits Corner fits Marking Fig.
- Page 10 All manuals and user guides at all-guides.com Avensis (T25) TOYOTA GENUINE AUDIO 14. Cut the marked position on the dash- board using a saw. Fig. 14 15. Cut the marked position on the dash- board using a saw. Fig. 15 16.
- Page 11 All manuals and user guides at all-guides.com Avensis (T25) TOYOTA GENUINE AUDIO 17. Fit the side bracket (L) and (R) onto the changer unit : Bolt (M5x8) (4x) Fig. 17 a) Fit the switch b) Fit the in-dash changer unit...
- Page 12 All manuals and user guides at all-guides.com Avensis (T25) TOYOTA GENUINE AUDIO 20. Fit the glove compartment : Hook (2x) Fig. 20 21. Cut the panel Fig. 22 Avensis (RHD) - 13 10-02...
- Page 13 All manuals and user guides at all-guides.com Avensis (T25) TOYOTA GENUINE AUDIO 22. Fit the panel Fig. 23 10-02 Avensis (RHD) - 14...
-
Page 14: Hide-Away 6 Cd-Changer Installation
All manuals and user guides at all-guides.com Avensis (T25) TOYOTA GENUINE AUDIO 3. HIDE-AWAY 6 CD-CHANGER INSTALLATION Remove the shift knob and shift cover using a nylon pry tool. : Clip (4x) : Nail (4x) Fig. 24 Remove the panel : Clip (5x) Fig. - Page 15 All manuals and user guides at all-guides.com Avensis (T25) TOYOTA GENUINE AUDIO Remove the audio unit : Bolt (4x) Fig. 28 Remove the cover : Screw (2x) Remove the centre console : Screw (4x) : Bolt (4x) Fig. 29 10-02...
- Page 16 All manuals and user guides at all-guides.com Avensis (T25) TOYOTA GENUINE AUDIO a) Remove the front door scuff plate (R). : Nail (5x) Remove the kick panel (R). : Nut (1x) Fig. 30 Remove the driver seat : Bolt w/washer (4x)
- Page 17 All manuals and user guides at all-guides.com Avensis (T25) TOYOTA GENUINE AUDIO Route the changer wire and wrap the connectors using tape : Tape (2x3) Vehicle Harness WITH POP UP DISPLAY Do not connect To audio AVC-LAN wire harness WITHOUT POP UP DISPLAY...
- Page 18 All manuals and user guides at all-guides.com Avensis (T25) TOYOTA GENUINE AUDIO a) Route the changer wire along the cross member and attach using tape (4x). b) Attach the excess wire of the changer wire onto the cross member using tape (6x).
- Page 19 All manuals and user guides at all-guides.com Avensis (T25) TOYOTA GENUINE AUDIO 13. Attach the adhesive tapes and the spacers ( ) to the base brack- using screws : Spacer (w/o nut) : Spacer (w/nut) : Tape (1x) * : Tape (cut to size 67mmx50mm) (1x) : Screw (M5x16) (2x) Fig.
- Page 20 All manuals and user guides at all-guides.com Avensis (T25) TOYOTA GENUINE AUDIO 15. Mount the side brackets (2x) to the changer unit : Bolt (M5x8) (4x) CAUTION CAUTION Loosen the screws before moving Screw them. Tighten up after the position is changed.
- Page 21 All manuals and user guides at all-guides.com Avensis (T25) Cut line precisely Cut a long hole Cut line 10-02 Avensis (RHD) - 22...
- Page 22 All manuals and user guides at all-guides.com TOYOTA GENUINE AUDIO 312N TEMPLATE precisely Cut line 10-02 Avensis (RHD) - 23...
- Page 23 All manuals and user guides at all-guides.com TOYOTA MOTOR CORPORATION...
