- Page 1 All manuals and user guides at all-guides.com Toyota Genuine Audio INSTALLATION INSTRUCTIONS RAV4 (RHD) - MMC (Production date 08/03) Manual Ref. n° A3RA2/W-2-0 TOYOTA MOTOR CORPORATION...
-
Page 2: Table Of Contents
All manuals and user guides at all-guides.com RAV4 (A2) TOYOTA GENUINE AUDIO TABLE OF CONTENTS 1. Audio Application Chart ............................. 2. System Layout ................................3. 1.4Din Audio Installation ............................4. Wide 2Din Audio Installation ............................5. Seat Mounted CD-Changer Installation (Passenger Seat) .................. -
Page 3: Audio Application Chart
All manuals and user guides at all-guides.com p. 1/2... - Page 4 All manuals and user guides at all-guides.com p. 2/2...
-
Page 5: System Layout
All manuals and user guides at all-guides.com RAV4 (A2) TOYOTA GENUINE AUDIO 2. SYSTEM LAYOUT 2.1 CD-CHANGER INSTALLATION UNDER THE PASSENGER SEAT NOTE: To install the CD-changer in hanging position under the passenger seat, you will need the seat-mounted 6 CD-changer TM0461 (08601-00912) and the seat-mounting kit F/K (08695-00803). -
Page 6: 4Din Audio Installation
All manuals and user guides at all-guides.com RAV4 (A2) TOYOTA GENUINE AUDIO 3. 1.4DIN AUDIO INSTALLATION Remove the covers : Clip (6x) Fig. 1 Remove the centre cluster panel : Clip (3x) : Screw (2x) Fig. 2 Remove the accessory boxes... - Page 7 All manuals and user guides at all-guides.com RAV4 (A2) TOYOTA GENUINE AUDIO Remove the brackets and panels from the cover plates : Screw (8x) Fig. 4 In case of 1.4DIN Combo + 0.6DIN Add on unit Mount the brackets (2x) onto the 1.4 DIN combo and 0.6DIN add on unit...
- Page 8 All manuals and user guides at all-guides.com RAV4 (A2) TOYOTA GENUINE AUDIO Before fitting the assembly (1.4DIN combo + 0.6DIN add on unit or 1.4DIN 11 10 combo + 0.6DIN cover plate) to the vehicle, remove the adhesive tape securing the vehicle connectors (18P...
-
Page 9: Wide 2Din Audio Installation
All manuals and user guides at all-guides.com RAV4 (A2) TOYOTA GENUINE AUDIO 4. WIDE 2DIN AUDIO INSTALLATION Remove the covers : Clip (6x) Fig. 10 Remove the centre cluster panel : Clip (3x) : Screw (2x) Fig. 11 Remove the accessory boxes... - Page 10 All manuals and user guides at all-guides.com RAV4 (A2) TOYOTA GENUINE AUDIO Remove the brackets and panels from the cover plates : Screw (8x) Fig. 13 Mount the brackets onto the audio assembly : Screw (8x) NOTE For part number see audio applica- tion chart pages 4 to 5.
-
Page 11: Seat Mounted Cd-Changer Installation (Passenger Seat)
All manuals and user guides at all-guides.com RAV4 (A2) TOYOTA GENUINE AUDIO SEAT MOUNTED CD-CHANGER INSTALLATION (Passenger Seat) Remove the covers : Clip (6x) Fig. 16 Remove the centre cluster panel : Clip (3x) : Screw (2x) Fig. 17 Remove the accessory boxes... - Page 12 All manuals and user guides at all-guides.com RAV4 (A2) TOYOTA GENUINE AUDIO Remove the passenger seat : Bolt w/washer (4x) : Cover (2x) Fig. 19 Remove the front door scuff plate (L) and kick panel (L) and side cover (L).
- Page 13 All manuals and user guides at all-guides.com RAV4 (A2) TOYOTA GENUINE AUDIO Route the changer wire and attach using tape Tape Not connected : Tape (7x) Not connected CAUTION Check that the wire is not stressed when the seat is moved to the front To Audio unit most or to the rear most position.
- Page 14 All manuals and user guides at all-guides.com RAV4 (A2) TOYOTA GENUINE AUDIO 10. Route the changer wire and attach using tape and a wire tie : Tape (4x) : Wire tie (1x) Fig. 24 11. Fit the side brackets (2x) and the...
- Page 15 All manuals and user guides at all-guides.com RAV4 (A2) TOYOTA GENUINE AUDIO 12. Fit the sub bracket (R) to the side bracket (R). : Bolt (M5x9) (2x) Hole Location ‘D’ Hole Location ‘B’ Fig. 26 13. Fit the sub bracket...
- Page 16 All manuals and user guides at all-guides.com RAV4 (A2) TOYOTA GENUINE AUDIO a) Fit the sub bracket (R) together with Holes (3x) the side bracket (R) and the spacer onto the passenger seat right Turn over hand. : Bolt (M6x12) (2x)
- Page 17 All manuals and user guides at all-guides.com RAV4 (A2) TOYOTA GENUINE AUDIO 17. Fit the CD-changer to the sub brackets (R) + (L), under the passenger seat using nuts : Nut (M6) (4x) Fig. 31 ENSURE THAT ALL REMOVED CONNECTORS ARE PUT BACK CORRECTLY.
-
Page 18: Subwoofer Installation
All manuals and user guides at all-guides.com RAV4 (A2) TOYOTA GENUINE AUDIO 6. SUBWOOFER INSTALLATION a) Fit the attachment bracket to the subwoofer : Bracket (2x) : Screw w/washer (4x) : Screw (4x) b) Fit the cushion tape to the sub-... - Page 19 All manuals and user guides at all-guides.com RAV4 (A2) TOYOTA GENUINE AUDIO Cut the tape (10 pieces). Fig. 34 a) Pull back the floor carpet b) Route and tape the subwoofer wire harness as shown. Fig. 35 Connect the subwoofer wire harness...
- Page 20 All manuals and user guides at all-guides.com RAV4 (A2) TOYOTA GENUINE AUDIO Before installing the subwoofer adjust the high cut and gain to the correct position as shown in the illustration. Fig. 37 a) Separate the felt from the floor car-...
-
Page 21: Genuine Parts
All manuals and user guides at all-guides.com GENUINE PARTS...
