Replacing a hard drive

Removing the hard drive

Status
Slot Number
Enclosure Device ID
Status
Slot Number
Enclosure Device ID
Status
In the output above, the hard drive whose status is not Ok is the one that must be
replaced. Take note of the Enclosure Device ID and Slot Number of the hard drive for
use in the remaining tasks.
Note
If all hard drives are Ok, confirm the drive bay number for the drive to be replaced.
Contact EMC Customer Support for clarification.
After identifying the node and the defective hard drive, perform the following steps to
replace the hard drive.
Procedure
1. From the front of the cabinet, press both tabs on the front of the bezel.
Figure 7 Bezel Removal
2. Pull the bezel away straight from the rack.
3. Using the physical disk ID provided by EMC Technical Support and verified above,
locate the defective hard drive.
: Ok
: 4
: 9
: Ok
: 5
: 9
: Ok
