- Page 1 Original instructions AVANTI SERVICE LIFT User’s Manual Model Service Lift OCTOPUS L95...
- Page 2 CE certificate for Octopus L95 :...
- Page 3 Date of publication: 3rd CE Edition: 07/2019 Revision 1: 30/07/2019 Manufacturer: Avanti Wind Systems Technology, S.L. Calle Ángeles (Los), Num. 88 Pol. Industrial Centrovía 50198 Muela (La) - (Zaragoza)- Spain P: +34 976 149524 F: +34 976 149508 E: info@avanti-online.com I: www.avanti-online.com...
-
Page 4: Table Of Contents
Appendix B: Stomp-test Instruction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34 AVANTI Service Lift for Wind Turbines AT00012569 OCTOPUS user CE 2nd EN R3.indd 4... -
Page 5: Limited Warranty
HEREBY EXCLUDED TO THE MAXIMUM of the Product. The sole and exclusive remedy EXTENT PERMITTED BY APPLICABLE LAW and the entire liability of Avanti under this AND ARE EXPRESSLY DISCLAIMED BY limited warranty, shall be, at the option of AVANTI. IF, PURSUANT TO ANY APPLICABLE... -
Page 6: Introduction
Additional copies are available from the manufacturer upon request. This manual, including, but not limited to, measurements, procedures, components, descriptions, instruc- tions, recommendations and requirements, is subject to change without prior notice. Please check Avanti website/manuals for the latest revisions of the manuals. -
Page 7: Cautions
2.4 Terms and definitions Terms Definitions Person who has received relevant training from Avanti or a qualified instructor associated with the Certified technician intended work and who holds valid certification (current) for the task in question. Person who has received relevant training associated with using the Avanti service lift and perform... -
Page 8: Description
Operating temp (Low temp version) -30ºC to +40ºC is a standard configuration and a low Max. noise level 80 dB (A) temperature configuration where traction system and main control box components are chosen specifically. AVANTI Service Lift for Wind Turbines... -
Page 9: Dimensions
3.5 Dimensions 1040 User’s Manual... -
Page 10: Components
5 Maintenance cover 14 External controls 6 Cabin control box 15 Top obstruction device 7 Bottom obstruction device 16 Safety wire rope 8 Guide ladder 17 Traction wire rope 9 Guiding rollers 18 Travelling cable pulley AVANTI Service Lift for Wind Turbines... -
Page 11: Traction Hoist
Power capacity speed current wire rope Ø approx. Version Traction system type m/min Octopus L95 M508 / 400V 50Hz Octopus L95 M508 / 690V 50Hz Octopus L95 M508 / 400V 60Hz Octopus L95 M508 / 480V 60Hz Octopus L95 M508 / 690V 60Hz 3.6.3 Fall arrest device... -
Page 12: Main Control Box
Overload buzzer Warning buzzer Fall arrest device triggered lamp 3.6.6.2 Platform control boxes Main switch UP button Emergency stop button DOWN button Ready lamp Optional for Octopus L95. Platform level lamp AVANTI Service Lift for Wind Turbines... -
Page 13: Platform Fences
This levelling condition is monitored by the platform level switch which is triggered by the safe zone plates. For the Octopus L95, as an option, the levelling condition can be monitored by a magnetic sensor. Safe zone plate... -
Page 14: Maintenance Cover
Release the DOWN button as soon as the rubber bumpers hit the floor. Otherwise the service lift or the installation may get damaged. AVANTI Service Lift for Wind Turbines... -
Page 15: Top Obstruction Device
Top obstruction device interrupts ascent if it encounters an obstacle. Descent will still be possible, for instance to remove the obstacle. In Octopus L95 these switches can be located When the top obstruction device switches on the top of the cabin, beside safety and are engaged, press the down button until it traction wire ropes. -
Page 16: Internal Light
During operation users must hook themselves up to the anchor points inside the cabin, in order to prevent falling risks. In case of need of evacuation, the evacuation procedure will be followed. AVANTI Service Lift for Wind Turbines... -
Page 17: Information Signs And Documents
3.6.22 Information signs and documents 3.6.23 Travelling cable pulley The manual and quick guide are accessible from inside Travelling cable is connected from power supply socket the cabin. The following documents, signs and labels over mid tower´s height platform to service lift socket are supplied with the service lift and shall always be and it is provided with a cable relief on each end. -
Page 18: Instructions For Use
DOWN button - the service lift descends. f) Top obstruction device: activate device by pressing it down. The service lift shall not move up until device is released. AVANTI Service Lift for Wind Turbines... -
Page 19: Prohibited Uses
4.2 Prohibited uses 4.6 Operation from outside the cabin (automatic send configuration) The consequences of not following below STOP STOP prohibitions are extremely hazardous to Transportation of people is forbidden if the operation the physical integrity of the users. is controlled from outside the cabin When using the service lift it is prohibited to: Operation by means of the user control box: •... -
Page 20: Overload Limiter
During manual descent if the bottom obstruction device hits an obstacle, the brake release lever is mechanically disengaged so the further descent is disabled. The system is automatically reset once the obstacle is removed. AVANTI Service Lift for Wind Turbines... -
Page 21: Troubleshooting
4.11 Troubleshooting 1. All tests and repairs to the electronic compo- 2. Repairs to the traction hoist, the fall arrest nents should be performed by certified device and to the system’s supporting compo- technicians only! The wiring diagram is nents should be performed by certified technicians only! placed in the power cabinet. - Page 22 AVANTI. but the lift can WARNING! go both up and Further use of lift may down. result in damage to the wire rope traction. AVANTI Service Lift for Wind Turbines...
-
Page 23: Out Of Service
Breakdown Cause Solution Service lift will Irresponsible behaviour Carefully take the service lift up and STOP go up but not jeopardizes system safety! remove the obstacle. down! Test the operational safety of affected D1 The service lift has platform components. encountered or is stuck on an Inform the supervisor. -
Page 24: Appendix A: Daily Inspection Log
The cabin (with 1 person inside) is ascended with a - Lock Out the installation from use and contact Avanti service lift user inside, and the cabin bottom is for further approach! positioned (“parked”) in a height of app. - Page 25 User’s Manual...
- Page 26 I: www.avanti-online.com E: info@avanti-online.com...
