EN-Instruction sheet

Parameters

Menu Parameters Cod Description
Setpoint Stp Setpoint
Thermostat tHE Thermostat settings
Setpoint adjustment
SPr Current setpoint adjustment value diF * SPr
ratio
Differential diF Thermostat differential
Air temperature
tAD Air Temp Adjust
adjust
Alarm ALA Alarm setting
High temperature Alarm is activated above this temperature
HAt
alarm (Celsius )
Low temperature Alarm is activated below this temperature
LAt
alarm (Celsius )
Compressor CoP Compressor Setting
Minimum time compressor must run 0-30
Min run time Crt
minutes
Minimum time compressor must idle 0-30
Min Stop time CSt
minutes
Maximum time compressor must idle 0-480
Max OFF time Cot
minutes
Compressor run time if temperature sensor is
Error run time Ert
not working (0-60 minutes )
Compressor stop time if temperature sensor is
Error stop time ESt
not working (0-60 minutes )
Minimum cut-in When compressor is OFF:
uLi
voltage lowest compressor start voltage (0-270 V)
Minimum cut-out When compressor is ON:
uLo
voltage lowest operation voltage (0-270 V)
When compressor is ON:
Maximum voltage uHi
highest operation voltage (0-270 V)
Delay in seconds between power ON &
Power ON delay Pod
compressor being activated
Defrost dEF Defrost Setting
No: defrost function is disabled,
Defrost type dFt
nat: OFF-cycle defrost (natural defrost)
Temp at which defrost stop
Terminating temp dtt
(evap temperature or cabinet temperature)
The minimum time in hours between the start
Def Min Interval dii
of each defrost cycle
The maximum time in hours between the
Def Max Interval dAi
start of each defrost cycle
The minimum duration of a defrost cycle
Def Min time dit
in minutes
The maximum duration of a defrost cycle
Def Max time dAt
in minutes
Condenser
Con Condenser protection settings
Protection
Condenser Alarm If condenser sensor exceeds this temperature,
CAL
Limit alarm is activated
Condens er Block If this temperature is exceeded, compressor
CbL
Lim it will be stopped
Temperature at which compressor may start
Condenser OK limit CoL
after a stop due to exceeding CbL
Temperature below which the compressor is
Condenser Low Temp CLL
not allowed to start
Display diS Display setting
Lock-time After
dLt Display lock time after defrost [0-60 min]
defrost
Danfoss can accept no responsibility for possible errors in catalogues, brochures and other printed material. Danfoss reserves the right to alter its products without notice. This also applies to products already on order provided that such alternations can be made without subsequential changes being necessary in specifica-
tions already agreed. All trademarks in this material are property of the respecitve companies. Danfoss and Danfoss logotype are trademarks of Danfoss A/S. All rights reserved.
Produced by Danfoss A/S (EL-MSSM/AZ) | March 2014
ERC 101 kit
De-
Assignments
Min Max Unit
fault
-50 80 C 2
S2 Application
0.0 1.0 - 0.0
DO1 configuration
0.0 20.0 K 2.0
Password level1
0.0 20.0 K 0
Password level2
Service
-50.0 80.0 C 15.0
Voltage value
-50.0 80.0 C -50.0
Relay 1 counter
Interval counter
Defrost time counter
0 30 min 0
Firmware version
0 30 min 0
Hardware version
0 480 min 0

Problem solving

0 60 min 0
Problem
0 60 min 0
Compressor does not start
0 270 Vac 0
0 270 Vac 0
E01 or E02 is shown on display
Display alternates between "Con" and
0 270 Vac 270
temperature
Display alternates between "Hi" and
0 300 Sec 180
temperature
Display alternates between "Lo" and
temperature
no nat - nat
0 25 C 7
0 96 hours 6
0 96 hours 7
0 240 min 10
0 480 min 30
0 85 C 75
0 85 C 85
0 85 C 60
-50 20 C -5
0 60 min 5
Assignments of inputs and outputs
Application to be controlled with Sensor
C. (nC=Not Connected, Sco= Temp control,
S2A nC Con -
EuA= Evap temp, Con=Cond temp {condenser
cleaning})
Relay output 1. compressor (CoP)
o1C CoP HeT -
2. Heater HeT
PS1 Shop owner Most common parameters 0 999 -
Service technician all parameters with read
PS2 permission and possibility to change a 0 999 -
number of parameters
Service
uAC Current main power supply voltage 0 270 Vac
Thousands of cycles of compressor relay since
rL1 0 999 1000
manufacture
int Compressor run time since last defrost 0 999 min
dnt Duration of last defrost cycle [min] 0 999 min
Fir Danfoss software version number - - -
HAr Danfoss hardware version number - - -
Probable cause Remedy
Waiting for compressor delay timer Check CoP->CSt
Line voltage to compressor too low or too high Check CoP->uLi, uLo, uHi
E01: Sensor "S1" defective
Replace sensor
E02: Sensor "S2" defective
Condenser temperature exceeds the Clean condenser,
temperature set in condenser settings menu Check Con->CAL, CbL
Temperature too high Check ALA->HAt
Temperature too low Check ALA-> LAt
DKRCC.EI.RL0.A3.02/520H8599
