Installation guide
ERC 214
Digital regulator for refrigeration and defrosting, 4 relays.
Dimensions (mm)
83
Assembly
Wiring diagram
Sair
S5
DO1
1
2
~
~
Electrical input
(on the basis of product code)
© Copyright Danfoss | Published by ADAP-KOOL | 2018.10
The ERC 214 is a smart, multipurpose integrated refrigeration controller with temperature
and defrost management, available with 4 relays.
This controller is for Operating temperature sensing control, suitable for refrigeration and
heating applications.
Incorporated control has been designed to fulfil today's requirements for commercial
refrigeration applications.
Assembly
DI1
DI2
DO4
DO1
DO2
DO3
Sc
DO2 DO3 DO4
3L
4N
5
6
7
~
~
61.2
66
Rear mount (clip fixing)
Quick programming tool: EKA 183B
GND
8
9
10
11
Sair
S5 Sc/DI1
Installation guide | ERC 214
71
29
Drilling template
Removal
GND
12
13
14
Connectors:
DI2
Max. Torque = 0.4 Nm
DKRCE.PI.RL0.N4.02 | 1
