Section 1 - Product Overview
1
1
Power Cord
Power Buttons /
2
Power Status LEDs
Reset Button /
3
System Status LED
4
USB Charging Port
5
Power Outlets
D-Link DSP-W320 User Manual
Hardware Overview
Plugs into your wall outlet.
Press this button to switch on or off the individual power outlet.
See LED Behavior on page 4 for LED behavior information.
Press and hold for this button until the System Status LED turns solid red to factory
reset it.
See LED Behavior on page 4 for LED behavior information.
Plug in a USB device that you wish to supply power to here.
Connect your appliances, lamps, or other electronic devices you wish to control
here.
2
3
4
5
3
