14. Place a jumper for non-latching output. A momentary short on these terminals resets output latching
[Trigger EOL Shutdown] (Fig. 1e, pg. 4).
15. Upon completion of wiring secure enclosure door with latches and optional lock.
WARNING: When installing in a non-restricted service area use lock or other fastened means on door
latches. This installation should be made by qualified service personnel and should conform to the
National Electrical Code and all local codes.
Red (DC)
ON
ON
OFF
OFF
Terminal
Function/Description
Legend
Connect 120VAC 60Hz to these terminals: L to hot, N to neutral(non power-limited)
L, G, N
(Fig. 1a, pg. 4).
– DC +
12VDC @ 10A continuous output (Non power-limited output).
(Fig. 1h, pg. 4)
Trigger EOL Trigger inputs can be normally open, normally closed from an output circuit
Supervised (power-limited input) (Fig. 1d, pg. 4).
NO, GND
Trigger input latching or non-latching (power-limited) (Fig. 1c, pg. 4).
RESET
Auxiliary power-limited output rated @ 1A (unswitched) (power-limited output)
+ AUX –
(Fig. 1f, pg. 4).
Indicates loss of AC power, e.g. connect to audible device or alarm panel.
AC Fail
Relay normally energized when AC power is present.
NC, C, NO
Contact rating 1A @ 30VDC (power-limited) (Fig. 1b, pg. 4).
Indicates low battery condition, e.g. connect to alarm panel.
Bat Fail Relay normally energized when DC power is present. Contact rating 1A @ 30VDC.
NC, C, NO A removed battery is reported within 5 minutes.
Battery reconnection is reported within 1 minute (power-limited) (Fig. 1b, pg. 4).
Stand-by battery connections. Maximum charge current 1.54A (non power-limited)
– BAT +
(Fig. 1g, pg. 4).
WayPoint102
LED Diagnostics:
Green (AC/AC1)
ON
OFF
ON
OFF
Terminal Identification:
Power Supply Status
Normal operating condition.
Loss of AC. Stand-by battery supplying power.
No DC output.
Loss of AC. Discharged or no stand-by battery. No DC output.
