ROLLAND ROLLFORCE Instruction Manual page 13

Element
Hydraulic Engine
Proportional Regulator
2 –way distributor
3-way distributor
Inductive wheel sensor
Inductive sensor on the
reductor
Pressure gauge
Manual regulator
Notice originale : Français
Function
Powered by oil,
maintains the reductor that
supplies the belt. A 160
cm³ engine for simple
drills and two motors of
130 cm³ mounted side by
side for double drills.
Ensures even
distribution throughout the
circuit, in proportion to any
given electrical
Pressure filter
changed annually. This unit
is fitted with two pressure
caps to safeguard emptying
and clearance operations.
Allows for oil feed for
shock absorbers and hatch
functions.
Allows for oil feed for
tappet and hatch
tractor funnel functions.
Gives the distance run with
the spreader in tow.
Indicate the
covered by the
absorber and
condition.
Inform the user of the oil
pressure within the circuit.
Ensure even distribution
of oil throughout
circuit. This is adjusted by
a rotary selector.
13
Stage in question
this
All models
oil
data.
111, 112, 113, 211, 212,
to be
121, 122, 123, 221, 222,
131, 132, 133, 231, 232,
and
112, 113, 122, 123, 132,
133, 212, 213, 222, 223,
distance
112, 113, 122, 123, 132,
shock
133, 212, 213, 222, 223,
their
112, 113, 122, 123, 132,
133, 212, 213, 222, 223,
the
213
223
233
232, 233
232, 233
232, 233
110
NT0002 V –p – 03/2014
