III.2 Measurement of ACV and ACA

Voltage:
a. Set the sliding switch at VA position.
b. Insert the test leads into the input jack. Connect the test prods of the test leads in
PARALLEL to the circuit to be measured.
NOTE: If the peak value of the input AC current is greater than the
maximum value of the range, then symbol of OL will be displayed.
