Tech Lighting Element CMH MR16 Installation Instructions Manual page 6

5C
TAB
3
3
ROUND PLASTER RING
4
3
3
CUT OUT
Line up the two tabs in back of the plaster ring with the
3
two cut out sections of the trim holder inside edge.
4 Push the plaster ring tabs into the cut out sections of the
trim holder edge.
TAB
3
3
SQUARE PLASTER RING
4
3
3
CUT OUT
5D
#8-32 SCREW
5
5
Secure the plaster ring in place with the two provided flat
5
head #8-32 screws. Make sure that the screws penetrate
through the drywall into the housing screw holes.
NOTE:
Do not overtighten the screws!
Overtightening may bend the plaster ring,
causing the plaster surface to come away from
the drywall.
5E
6
Plug the trim holder with the provided dust shield.
6
7 Properly plaster onto the plaster ring and drywall.
5F
8
Finish around the trim to match drywall.
8
6
#8-32 SCREW
5
5
6
8
