Tech Lighting Element CMH MR16 Installation Instructions Manual page 3

Connect Power to the Housing
3A
ELECTRICAL
BOX COVER
1
Push up on the tabs on the electrical box and remove the
1
electrical box cover.
3B
2
3
Install the conduit to the housing electrical box.
2
Run the power line wires into the housing electrical box.
3
WARNING:
RISK OF FIRE: When using the
housing electrical box for power feed through,
MAX
use 4 - #12 AWG, or 6 - #14 AWG branch
circuit wires.
TABS
3C
5
4
Connect the neutral power line wire to the white
4
transformer wire and the white thermal protector wire with
a wire nut.
Connect the hot power line wire to the black thermal
5
protector wire with a wire nut.
Connect the fixture ground wire and the green transformer
6
wire to a suitable ground according to local electrical
codes.
Replace the electrical box cover. Make sure that the top
7
edge of the cover snaps under the tabs.
3
6
6
