CHIEF KSA-1020 Installation Instructions Manual

Wall and desk cpu mount
Hide thumbs Also See for KSA-1020:

Advertisement

Quick Links

Download this manual
I N S T A L L A T I O N I N S T R U C T I O N S
Instrucciones de instalación
Installationsanleitung
Instruções de Instalação
Istruzioni di installazione
Installatie-instructies
Instructions d´installation
Wall and Desk CPU Mount
Spanish Product Description
German Product Description
Portuguese Product Description
French Product Description
Italian Product Description
Dutch Product Description
KSA-1020

Advertisement

loading
Need help?

Need help?

Do you have a question about the KSA-1020 and is the answer not in the manual?

Questions and answers

Related Manuals for CHIEF KSA-1020

Summary of Contents for CHIEF KSA-1020

  • Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Instrucciones de instalación Istruzioni di installazione Installationsanleitung Installatie-instructies Instruções de Instalação Instructions d´installation Wall and Desk CPU Mount Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description KSA-1020...

  • Page 2: Important Warnings And Cautions

    Reinforce the structure as required before installing the Chief® is a registered trademark of Milestone AV Technologies. component. The wall to which the mount is being attached All rights reserved.

  • Page 3: Tools Required For Installation

    Installation Instructions KSA-1020 LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación...
  • Page 4 KSA-1020 Installation Instructions ASSEMBLY If hanging mount underneath desk, remove mounting buttons to reinstall them in the holes in which they will be used. Installation of Protective Rubber Edging • If mounting vertically, move mounting buttons to Place four strips of protective rubber edging (C) over the the four holes on top of the mount.

  • Page 5: Wall Mount Installation

    Installation Instructions KSA-1020 Loosen adjustment knobs on top and bottom of the mount Tighten front strap to desired tension. and slide flanges in order to allow for the CPU to be inserted WALL MOUNT INSTALLATION for mounting. (See Figure 5)
  • Page 6 KSA-1020 Installation Instructions Site Requirements for Using Steel Studs WARNING: IMPROPER INSTALLATION CAN LEAD TO EQUIPMENT FALLING CAUSING SERIOUS PERSONAL INJURY OR DAMAGE TO EQUIPMENT! The figure below identifies the minimum requirements for installation of display mounts onto a steel stud structure. If the structure or its components do not meet these requirements contact the mount manufacturer for specific instructions before attempting installation.
  • Page 7 Installation Instructions KSA-1020 Installing to Steel Studs or Drywall Steel Stud Drywall WARNING: IMPROPER INSTALLATION CAN LEAD TO EQUIPMENT FALLING CAUSING SERIOUS PERSONAL INJURY OR DAMAGE TO EQUIPMENT! Plastic Cap Determine location for mount keeping in mind CPU size and safety requirements.
  • Page 8 KSA-1020 Installation Instructions Place mounting bracket over anchors and align mounting holes in mounting bracket with holes in anchors. (See Figure 13) 10. Insert 1/4-20 x 1-3/4" Phillips pan head screw (E) into mounting hole on mounting bracket and into anchor (B) and tighten until flush against mounting bracket.
  • Page 9 Installation Instructions KSA-1020 Installing Mount to Desk (desk not shown) Latching flag WARNING: Failure to provide adequate structural strength for this component can result in serious personal injury or damage to equipment! It is the installer’s responsibility to make sure the desk to which this component is attached can support five times the combined weight of all equipment.
  • Page 10 KSA-1020 Installation Instructions...
  • Page 11 Installation Instructions KSA-1020...
  • Page 12 Europe A Fellenoord 130 5611 ZB EINDHOVEN, The Netherlands P +31 (0)40 2668620 F +31 (0)40 2668615 Chief Manufacturing, a products division of Asia Pacific A Office No. 1 on 12/F, Shatin Galleria Milestone AV Technologies 18-24 Shan Mei Street...
