I N S T A L L A T I O N I N S T R U C T I O N S
Instrucciones de instalación
Installationsanleitung
Instruções de Instalação
Istruzioni di installazione
Installatie-instructies
Instructions d´installation
Wall and Desk CPU Mount
Spanish Product Description
German Product Description
Portuguese Product Description
French Product Description
Italian Product Description
Dutch Product Description
KSA-1020

Advertisement

loading
Need help?

Need help?

Do you have a question about the KSA-1020 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for CHIEF KSA-1020

  • Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Instrucciones de instalación Installationsanleitung Instruções de Instalação Istruzioni di installazione Installatie-instructies Instructions d´installation Wall and Desk CPU Mount Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description KSA-1020...
  • Page 2: Important Warnings And Cautions

    KSA-1020 DISCLAIMER Milestone AV Technologies, and its affiliated corporations and subsidiaries, (collectively, Milestone) intend to make this manual accurate and complete. However, Milestone makes no claim that the information contained herein covers all details, conditions or variations, nor does it provide for every possible contingency in connection with the installation or use of this product.
  • Page 3 À la main Hex-Head Wrench Llave de cabeza hexagonal Sechskantschlüssel Chave de cabeça sextavada Chiave esagonale Zeskantsleutel Clé à tête hexagonale KSA-1020 Pencil Mark Marcar con lápiz Stiftmarkierung Marcar com lápis Segno a matita Potloodmerkteken Marquage au crayon Drill Hole...
  • Page 4: Tools Required For Installation

    Installation Instructions KSA-1020 TOOLS REQUIRED FOR INSTALLATION 7/64" 1/2" 17/64" 1/2" PARTS B(2) C(4) 3" A(1) E(2) D(1) 1/4-20 X 1 3/4" G(2) F(1) 3/8 X 1 1/4" #12 X 2 1/2"...
  • Page 5: Assembly And Installation

    CPU to be inserted for mounting. (See Figure 5) NOTE: Top and bottom knobs can be removed and inserted into the front square holes in order to allow for large KSA-1020 Horizontal button location Figure 3 Figure 4...
  • Page 6: Wall Mount Installation

    KSA-1020 CPU’s to be installed. (See Figure 5) NOTE: Flanges may be reversed in order to allow for narrow CPU’s to be installed in a secure manner. If this is done, be sure to also to remove and reinstall strap so that the buckle is facing out for easy adjustment.
  • Page 7 Stud type and structural strength must conform to the North American Specification for the Design of Cold-Formed Steel Structural Members. [362 S 125 18, C-Shaped, S-Stud Section] Figure 8 KSA-1020 There must be a minimum of 1 7/8" (48mm) clearance inside wall...
  • Page 8 KSA-1020 Wall Mounting Using Steel Studs or Drywall After determining the site meets the installation requirements: Identify desired mounting location on wall. Using a stud finder or similar method locate stud. Align mounting holes in mount with stud making sure mounting holes are centered on stud.
  • Page 9 Using bracket and bearing (D) as a template, mark and drill one 17/64" diameter pilot hole through underside of desk at desired mounting location. Ensure entire mount will clear the outer edge of desk. (See Figure 16) KSA-1020...
  • Page 10 KSA-1020 desk mounting bracket Figure 16 Install 3/8 x 1 1/4" hex head lag screw (F) through bearing (D) and bracket into hole drilled in Step 2. (See Figure 16) Ensure bracket flag is in the open position. Insert four mounting buttons into four mounting holes on the bracket.
  • Page 11 Installation Instructions KSA-1020...
  • Page 12 KSA-1020 Chief Manufacturing, a division of Milestone AV Technologies 8834-000003 ©2008 Milestone AV Technologies www.chiefmfg.com 10/08 USA/International A 8401 Eagle Creek Parkway, Savage, MN 55378 P 800.582.6480 / 952.894.6280 F 877.894.6918 / 952.894.6918 Europe A Fellenoord 130 5611 ZB EINDHOVEN, The Netherlands...
