CHIEF KFCD-110 Installation Instructions Manual

I N S T A L L A T I O N
Small Flat Panel
Dual Swing Arm Desk Mount (KFCD-110)
The KFCD is a sleek design providing a broad range of viewing
for Small Flat Panel Displays.
At only 2.15" deep in the closed position, the mount allows
side-to-side pivot adjustment up to 180 degrees in the closed
and the fully extended position. Displays up to 30" (max. 40
pounds) can be extended to 14.2" from the wall and can pivot
360 degrees.
The KFCD accommodates all VESA® 75mm/100mm compliant
displays.
BEFORE YOU BEGIN
• Caution: To prevent damage to the KFCD, which could affect or void the Factory warranty, and to the
equipment that will be attached to it, thoroughly study all instructions and illustrations before you begin
the installation. Pay particular attention to the "Important Warnings and Precautions" on Page 1.
• The maximum weight to be installed on the KFCD wall mount is 40 pounds (18.1 Kg)
• The KFCD wall mount is designed to be installed using horizontal table tops and work surfaces. The surface to
which the KFCD wall mount is anchored must be capable of supporting five times the total weight of the mount
and all attached equipment.
• If you have any questions about this installation, contact Chief Manufacturing at 1-800-582-6480.
CHIEF MANUFACTURING INC.
1-800-582-6480 952-894-6280 FAX 952-894-6918
12800 HIGHWAY 13 SOUTH, SUITE 500
SAVAGE, MINNESOTA 55378 USA
I N S T R U C T I O N S
PART NO. 8832-000017 (Rev. A)
2003 Chief Manufacturing
www.chiefmfg.com
Printed in USA 12-03
