- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Universal Slat Wall Dual Arm Mounts KSG110...
-
Page 2: Important Warnings And Cautions
KSG110 DISCLAIMER CSAV, Inc., and its affiliated corporations and subsidiaries (collectively, "CSAV"), intend to make this manual accurate and complete. However, CSAV makes no claim that the information contained herein covers all details, conditions or variations, nor does it provide for every possible contingency in connection with the installation or use of this product. - Page 3 À la main Hex-Head Wrench Llave de cabeza hexagonal Sechskantschlüssel Chave de cabeça sextavada Chiave esagonale Zeskantsleutel Clé à tête hexagonale KSG110 Pencil Mark Marcar con lápiz Stiftmarkierung Marcar com lápis Segno a matita Potloodmerkteken Marquage au crayon Drill Hole...
-
Page 4: Tools Required For Installation
KSG110 TOOLS REQUIRED FOR INSTALLATION PARTS C (1) 3/16" 3/16" (Provided) A (1) D (1) 5/32" F (2) 8-32 x 3/8" Installation Instructions 5/32" (Provided) B (1) E (1) G (1) -
Page 5: Display Installation
IMPROPER INSTALLATION CAN LEAD TO DISPLAY FALLING CAUSING SERIOUS PERSONAL INJURY OR DAMAGE TO EQUIPMENT! Using screws of improper size may damage your display! Proper screws will easily and completely thread into display mounting holes. KSG110 Figure 2 Figure 3... - Page 6 KSG110 CAUTION: IMPROPER INSTALLATION CAN LEAD TO DISPLAY FALLING CAUSING SERIOUS PERSONAL INJURY OR DAMAGE TO EQUIPMENT! Inadequate thread engagement in display may cause display to fall! Back out screws ONLY as necessary to allow installation of Centris bracket! Ensure Centris cup is able to swivel and tilt easily, yet still be tight enough to hold display in desired position.
-
Page 7: Cable Management
CLOSED Position Installation is complete. Adjustments Centris Head Tension Adjustment 1. If previously attached, disconnect cables from display, remove display. KSG110 Cable Management Bracket (in open position) Cable Path (typical) Figure 8 Ensure that adequate cable slack exists for Cable Path... -
Page 8: Display Adjustment
KSG110 2. Using Phillips screwdriver, slightly loosen or tighten the adjustment screw as necessary (See Figure 10). Adjustment Screw Figure 10 3. Reinstall display. See Display Installation in this document. Display Adjustment Lateral position on display: Using your fingers, slightly loosen adjustment knob "A". - Page 9 Installation Instructions KSG110...
- Page 10 KSG110 8832-000237 2007 Chief Manufacturing www.chiefmfg.com 08/07 USA/International A 8401 Eagle Creek Parkway, Savage, MN 55378 P 800.582.6480 / 952.894.6280 F 877.894.6918 / 952.894.6918 Europe A Fellenoord 130 5611 ZB EINDHOVEN, The Netherlands P +31 (0)40 2668620 F +31 (0)40 2668615...
