Summary of Contents for CHIEF KRAMS K1W110
- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Shown with K1W220 Kontour™ Steel Stud Adapter Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description...
-
Page 2: Important Safety Instructions
9 lbs 18 lbs ACCESSORY: AN ACCESSORY is the secondary Chief (4.08 kg) (8.16 kg) product which is attached to a primary Chief product, and may have a component attached or setting on it. K1W110 25 lbs 25 lbs (11.34 kg) (11.34 kg) -
Page 3: Installation Instructions
Installation Instructions KRAMS LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación Perforar... -
Page 4: Tools Required For Installation
KRAMS Installation Instructions DIMENSIONS 4.45 113.0 8.53 3.22 7.50 216.8 81.7 190.5 2.14 54.4 TOOLS REQUIRED FOR INSTALLATION 1/2" (12.7mm) 1/2" (12.7mm) PARTS Hardware bag (only 3 of each required) B (4) C (4) 1/4-20 x 1 3/4" 1/4" D (4) 1/4"... -
Page 5: Site Requirements
Installation Instructions KRAMS Site Requirements (Must be centered over stud) If back side of wall is unfinished, drywall must be installed to a minimum of one stud left and right of the studs being used to install the mount. Drywall must be secured to stud with screws 12"... -
Page 6: Assembly And Installation
Assembly And Installation Steel Stud IMPORTANT ! : The KRAMS accessory is designed to Drywall mount Chief’s K1W or K2W Series mounting systems to a steel studs wall. Do not attempt to install any other mounting system to this accessory. Plastic Cap Hold adapter plate (A) up to the wall on top of steel stud at desired mounting location. - Page 7 Installation Instructions KRAMS 11. Use 1/4-20 hex nut to secure K1W/K2W Series wall plate (included with K1W/K2W mount) to adapter plate (A). (See Figure 6) 12. Use 1/4-20 x 1 3/4" Phillips pan machine screw (B) and 1/4" washer (C) to secure K1W/K2W Series wall plate to adapter plate (A).
- Page 8 Europe A Franklinstraat 14, 6003 DK Weert, Netherlands P +31 (0) 495 580 852 F +31 (0) 495 580 845 Chief, a products division of Asia Pacific A Office No. 918 on 9/F, Shatin Galleria Milestone AV Technologies 18-24 Shan Mei Street...
