I N S T A L L A T I O N I N S T R U C T I O N S
Instrucciones de instalación
Installationsanleitung
Instruções de Instalação
K2W110
K2W21H
K2W220
Istruzioni di installazione
Installatie-instructies
Instructions d´installation
K2W120
K2W22H
K2W Wall Mounts
Spanish Product Description
German Product Description
Portuguese Product Description
Italian Product Description
Dutch Product Description
French Product Description
K2W Series

Advertisement

loading
Need help?

Need help?

Do you have a question about the K2W Series and is the answer not in the manual?

Questions and answers

Summary of Contents for CHIEF K2W Series

  • Page 1 Instrucciones de instalación Istruzioni di installazione Installationsanleitung Installatie-instructies Instruções de Instalação Instructions d´installation K2W110 K2W120 K2W21H K2W22H K2W220 K2W Wall Mounts Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description K2W Series...
  • Page 2: Important Safety Instructions

    However, Milestone makes no all components located between the K2W Series Monitor Arm claim that the information contained herein covers all details, up to (and including) the display does not exceed the weight conditions or variations, nor does it provide for every possible limit listed below.
  • Page 3 Installation Instructions K2W Series DIMENSIONS K2W110 6.75 171.5 MOUNTING PATTERN COMPATIBILITY 100 X 100 75 X 75 TILT RANGE 15 DOWN 7.03 178.6 1.36 34.4 K2W120 2.32 59.0 MOUNTING PATTERN COMPATIBILITY 100 X 100 75 X 75 TILT RANGE 15 DOWN 10.32...
  • Page 4 K2W Series Installation Instructions K2W21H 1.38 34.9 MOUNTING PATTERN INTERFACE COMPATIBILITY ROTATION 100 X 100 10 DOWN RANGE 75 X 75 6.18 156.9 K2W22H 6.75 171.5 MOUNTING PATTERN INTERFACE COMPATIBILITY ROTATION 100 X 100 10 DOWN RANGE 75 X 75 9.46...
  • Page 5 Installation Instructions K2W Series K2W220 1.38 34.9 TILT RANGE 15 DOWN MOUNTING PATTERN COMPATIBILITY 100 X 100 75 X 75 11.99 304.5 1.36 34.4...
  • Page 6 K2W Series Installation Instructions LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación...
  • Page 7: Tools Required For Installation

    Installation Instructions K2W Series TOOLS REQUIRED FOR INSTALLATION 3/16” (included) 1/8” (included) PARTS A (1) *single display models/ [Arm assembly] (K2W120 shown) dual display models D (4/8)* B (4/8)* C (4/8)* M10x5.3x10 M4x25mm M4x14mm K2W models only! G (2) H (2) 1/4 x 2 1/2”...
  • Page 8 Figure 1 Assembly And Installation spacer (J12) if additional cable management is desired. (See Figure 2) Connecting K2W Series (wall mount) to Wall Determine mounting location on wall. (K1W22H shown) Use a stud finder to locate 2" x 4" wood stud.
  • Page 9: Display Installation

    It is the installer’s responsibility to make sure the combined weight of all components located between the K2W Series Monitor Arm up to (and including) the display does not exceed the weight limit listed. Use with products heavier than the maximum weight indicated may result in collapse of the mount and its accessories causing possible injury.
  • Page 10 K2W Series Installation Instructions (for flush mounting holes) quick release faceplate (B) x 4 (C) x 4 (D) x 4 Figure 6 For recessed mounting hole installation: • Place four spacers (D) on top of mounting holes on back of display. (See Figure 7) Figure 4 •...
  • Page 11 Installation Instructions K2W Series Position display with faceplate attached above mount. (See Figure 8) Slide faceplate onto mounting head until quick release tab clicks into place. (See Figure 8) (J2) Figure 10 Adjustments Figure 8 Portrait Adjustment (K2W21/22H Models only)
  • Page 12 K2W Series Installation Instructions Adjustments - K2W21H/22H models only Loosen knobs securing faceplates to array. (See Figure 12) Slide displays laterally on array to adjust lateral shift. (See Figure 12) Adjust pitch and pivot position as desired. (See Figure 12) Tighten knobs to secure faceplates in position.
  • Page 13: Cable Management

    Installation Instructions K2W Series Cable Management Route cables through cable management channels. (See Figure 15) cable (typical) Figure 15 Array Models Install cable clips (J7) to back of array. (See Figure 16) Route cables through cable clips (J7) as desired. (See...
  • Page 14 K2W Series Installation Instructions...
  • Page 15 Installation Instructions K2W Series...
  • Page 16 Europe A Franklinstraat 14, 6003 DK Weert, Netherlands P +31 (0) 495 580 852 F +31 (0) 495 580 845 Chief, a products division of Asia Pacific A Office No. 918 on 9/F, Shatin Galleria Milestone AV Technologies 18-24 Shan Mei Street...
