▶ Planer Blades
must be handled carefully to avoid
injury to the user or damage to the
blades.
changing planer blades. Edges are
sharp and may cause injury.
The PA1202 Woodrazor micro-grain
tungsten carbide planer blades have two
cutting edges, and may be reversed
when one of the cutting edges becomes
dull or chipped.
Do not attempt to sharpen or use
resharpened used blades of any kind. Use
only blades designated for use with this
model, because other blades will cause
vibration, decrease performance and may
not clamp securely in blade holder.
▼ REVERSING OR REPLACING
BLADES
To reverse or replace the blade, loosen
the clamping screws with blade wrench.
The wrench is stored on the left side of
the tool (Fig. 1). With the screws
loosened, slide the blade lengthwise out
of the cutter drum, taking care to keep
your fingers away from the sharp edges
of the blade (Fig. 4).
A piece of wood may be used for this
purpose. If the blade is gummed and
difficult to remove, you may clean the
blade with mineral spirits, lacquer
thinner or alcohol.
Clean all surfaces before reinstalling the
new blade, as this will ensure an
accurate blade setting and proper tool
performance.
▶ Trigger "ON/OFF" Switch
starting the tool, since torque from the
motor can cause the tool to twist.
continuously being depressed, the
trigger cannot be released.
Assembly
The planer blades are
sharp and fragile and
Wear
protective
gloves
when
Operating Instructions
Hold the tool with
both hands while
If the "Lock-ON"
button
is
-10-
Fig. 4
CUTTER
DRUM
CLAMPINg
SCREw
Fig. 5
CUTTER
DRUM
CLAMPINg
SCREw
▼ BLADE ALIGNMENT
The blade should be centered relative to
the front and rear shoes. (Fig 5.) Rotate
the blade drum by hand to verify sure
that the blade doesn't touch to any
other part of the tool.
Make sure the blade sits correctly in the
holder groove of the cutter drum.
You may then tighten the clamping
screws which secure the blade and your
planer is ready for use.
Before plugging the tool in, check that
the trigger lock is "OFF". Accidental
start-ups could cause injury.
of the switch "Lock-ON" button. If the
switch is locked "ON" during the use, be
ready for emergency situations to switch
it "OFF".
2.5 MM
BLADE
wRENCH
BLADE
2.5 MM
BLADE
wRENCH
Never
leave
the
trigger locked "ON".
Be aware of the
location and setting
