2.6 CD Cubicle

2.7 TT Cubicle

2.8 DB Cubicle

Direct Incoming Cubicle (CD)
Cubicle incoming or outgoing
cables direct.
Voltage Transformer
Cubicle (TT)
Cubicle for measure voltage
with protection of VT's by
fuses.
Bars Protection Cubicle (DB)
Cubicle for protection bars
and measuring the current
and/or voltage.
Versions are available with
arrival to the right or left.
