Accessories and Part Numbers
Adapter Plates
A variety of optional architectural adapter plates for
pass-through connections may be ordered for the switcher. The
SW2 VGA DA2 AF R can hold up to two (2) adapter plates. The
following configurations of adapters could be installed in either
interface:
• two adapter plates with a "plate size" of one, or
• one adapter plate of plate size two.
The tables on the following pages list the available adapter plates.
Blank Plate (no connector)
Single Space
2 - BNC
3 - BNC
2 - RCA to Solder Cups
3 - RCA to Solder Cups
2 - S-video
2 - F Connectors
2 - 1/4" Stereo Phono
2 - 3.5mm Stereo Mini
www.camboard.de
A-6
SW2 VGA DA2 AF R • Accessories and Part Numbers
CAMBOARD Electronics
Blank Plate (no connector)
Double Space
5 - BNC (Double)
2 - RJ-11
1 - D-9 Pass Through Connector
1 - HD-15 Pass Through Connector
1 - 3-pin XLR Connector
