JCM UBA Pro RQ Series Integration Manual page 48

Section 8
Recycler Transport
LED LED
OFF
OFF
ON
ON
OFF
ON
ON
ON
OFF
ON
ON
OFF
OFF
ON
ON
OFF
OFF
ON
ON
OFF
OFF
ON
P/N 960-000209R_Rev. A
UBA Pro RT/RQ™ Series Banknote Recycler
Table 21 LED Error Codes (Continued)
Status LED*
ON
OFF
OFF
ON
Flashes 6 Times
OFF
OFF
OFF
Flashes 7 Times
OFF
OFF
Flashes 8 Times
OFF
OFF
Flashes 9 Times
OFF
OFF
Flashes 10 Times
OFF
* Status LED color shows the Unit's operation
White: While powering up
Green: Stand-by
Magenta: While collecting
Cyan: While dispensing
Error Causes
RT Transport: Recycler Drum 1 and/or Drum 2 speed
adjustment error
RQ Transport: Recycler Drum 1 and/or Drum 2 speed
adjustment error
Dispensing error. Banknote is longer than specified length.
Dispensing error. Banknote is longer than specified length.
Dispensing error. Banknote is shorter than specified length.
Dispensing error. Banknote is shorter than specified length.
RT Transport: Flapper timeout
RQ Transport: Flapper timeout
RT Transport: Flapper Lever error
RQ Transport: Flapper Lever error
RT Transport: Flapper Motor lock-up
RQ Transport: Flapper Motor lock-up
© 2019, JAPAN CASH MACHINE CO., LTD.
3 8
Troubleshooting
Blue: After dispensed
Yellow: While accepting
Red: After accepted
