MOUNTING INSTRUCTIONS
Attaching the antenna to the antenna bracket
The antenna is attached to the antenna bracket by means
of the antenna arm. To do this, place the antenna-arm joint
socket onto the joint head of the antenna bracket. Tighten
this joint with the wing screw or hexagon socket screw
supplied. Whichever screw you use, please be sure to use
the washer supplied.
Attaching the antenna to a suspended ceiling
This requires a 3-cm diameter hole in the suspended ceiling.
First stick the insulation disk to the antenna. This acts as a
washer and protects the ceiling and the antenna. Insert the
cables and the screw thread through the hole in the ceiling.
Then screw the locking screw onto the screw thread and
tighten it.
Important
Working responsibly with high frequencies
The AirLancer ON-T360ag meets the requirements of
the R&TT directives 1995/5/EC and the FCC & ARPANSA
regulations. To ensure compliance with these requirements,
a minimum distance of 20 cm must be maintained between
the antenna and the human body when operating the
antenna.
Important
Electrical and electronic equipment law
In the interests of recycling, please do not dispose of
electrical and electronic waste in your household garbage.
Ensure that your electrical and electronic waste is disposed
of in accordance with the regulations in your country.
