Meter Description
FRONT PANEL VIEW
1.
Input / Output terminals
2.
LCD Display
3.
Buttons
4.
Battery compartment (on rear)
5.
AC adaptor input
TOP VIEW
1.
Optically isolated INPUT jack
2.
Optically isolated OUTPUT jack
3.
Non-isolated INPUT jack
4.
Non-isolated OUTPUT jack
BUTTON DESCRIPTION
1.
Power switch
2.
Date/Time
3.
Function
4.
Enter/Clear
5.
Sample Rate
6.
Pause
5
TOP VIEW
ISOLATE
IN
OUT
1
2
1
2
4
2
AUTO MANUAL %
REC
OUT
DIRECT
IN
OUT
3
4
3
5
6
V5.0 5/06
