Chapter 3
Summary of Parameters
This chapter summarizes all 10 of the parameter groups. For complete descriptions of i
iindividual parameters refer to the english manual.
No. No. Parameter Parameter Function Function
No. No. No. Parameter Parameter Parameter Function Function Function
Name Name Name Name Name Explanation Explanation Explanation Explanation Explanation
00 Master Speed Master frequency
Frequency source select
Setting
01 Operation Operation
Command command
Source source select
02 Motor stop Motor stop
method method select
03 V/F Curve Max output freq.
04 Setting Max voltage freq.
05 (13 & 14) Max output volt
06 Mid-point freq.
07 Mid-point volt
08 Min output freq.
09 Min output volt
10 Accel/Decel Acceleration time 1 d0.1 - d600. s
11 Time Setting Deceleration time 1 d0.1 - d600. s
12 Acceleration time 2 d0.1 - d600. s
Parameter Parameter
Parameter Parameter Parameter
V V V V V alue alue alue alue alue
d00:Master frequency input
determined by the digital
control panel
d01:Master frequency input
determined by t he analog
signal (DC 0 to +10 V)
d02:Master frequency input
determined by the analog
signal (DC 4 to 20 mA)
d00:Operating instructions
determined by the digital
control panel
d01:Operating instructions
determined by the external
terminal connections,
keypad STOP key effective
d02:Operating instructions
determined by the external
terminal connections, keypad
STOP key not effective
d00:RAMP stop
d01:Coasting to stop
d50.0 - d400.0 Hz
d10.0 - d255.0 V
d2.0 - d255.0 V
d0.1 - d400. Hz
d2.0 - d255.0 V
d0.1 - d20.0 Hz
d2.0 - d50.0 V
9
Factory Factory
Factory Factory Factory
Setting Setting Setting Setting Setting
d00
d00
d00
d60.0
d60.0
d220.
d1.50
d12.0
d1.50
d12.0
d10.0
d10.0
d10.0
