UC-8112-ME-T Series Hardware

Diagnosing Device and Subsystem Failures

The red LED will start blinking once you press the function button (FN). Keep the button pressed until the green
LED is lit for the first time and then release the button to enter diagnostic mode to check which peripherals are
available on the UC-8112-ME-T-LX. When the diagnostic program is running, the red LED will blink.
Status
Diagnostics program is executing
The following two tables describe the diagnostics results related to hardware defects and system operation.
Hardware Defects
If you observe any of these hardware issues, contact Moxa Support for further instructions.
Status
UART1 device issue
UART2 device issue
LAN 1 device issue
LAN 2 device issue
Button device issue
TPM device issue
LED device issue
System Operation
If you observe any of the following issues, check the item indicated by the LEDs.
Status
CPU usage (over 90%)
RAM usage (over 90%)
Disk usage (over 90%)
File system corrupted

Reset to Factory Default

Press and hold the function button (FN) continuously for at least 5 seconds to load the factory default
configuration. After the factory default configuration has been loaded, the system will reboot automatically.
The Power LED will blink on and off for the first 5 seconds, and then maintain a steady glow once the system
has rebooted.
We recommend that you only use this function if the software is not working properly and you want to load
factory default settings. The Reset to Default functionality is not designed to hard reboot the UC-8112-ME-T.
ATTENTION
Reset to Default will erase all the data stored on the boot storage
Please back up your files before resetting the system to the factory default configuration. All the data stored
in the UC-8112-ME-T's boot storage will be erased when it is reset to the factory default configuration.

Real-Time Clock

The UC-8112-ME-T's real-time clock is powered by a lithium battery. We strongly recommend that you do not
replace the lithium battery without help from a qualified Moxa support engineer. If you need to change the
battery, contact the Moxa RMA service team.
Red LED
Blinking
Red LED
On
On
On
On
On
On
On
Red LED
Blinking
Off
Off
Blinking
2-4
Yellow LED
Off
Yellow LED
On
On
Off
Off
Blinking
Blinking
Off
Yellow LED
On
On
On
On
Hardware Introduction
Green LED
On
Green LED
Off
Blinking
Off
Blinking
Off
Blinking
Off
Green LED
Off
Off
Blinking
Blinking
