Download this manual See also: Service Manual, Reference Manual
Enlarged version
™
™
Sun
Ultra
UltraSPARC
The Network Is the Computer
Sun Microsystems Computer Company
2550 Garcia Avenue
Mountain View, CA 94043 USA
415 960-1300
fax 415 969-9131
Part No.: 805-0937-10
Revision A, March 1997
2
™
-II Module X-Option
™

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ultra 2 and is the answer not in the manual?

Questions and answers

Related Manuals for Sun Microsystems Ultra 2

Summary of Contents for Sun Microsystems Ultra 2

  • Page 1 ™ ™ Ultra ™ UltraSPARC -II Module X-Option The Network Is the Computer ™ Sun Microsystems Computer Company 2550 Garcia Avenue Mountain View, CA 94043 USA 415 960-1300 fax 415 969-9131 Part No.: 805-0937-10 Revision A, March 1997...
  • Page 2 Sun. Sun, Sun Microsystems, le logo Sun, Ultra, OpenBoot, et Solaris sont des marques déposées ou enregistrées de Sun Microsystems, Inc. aux Etats- Unis et dans d’autres pays.

  • Page 3: Electromagnetic Compatibility

    Electromagnetic Compatibility FCC Class B Notice — United States This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause operation.
  • Page 4 Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de la classe B prescrites dans le Règlement sur le brouillage radioélectriques édicté par le Ministère des Communications du Canada. Sun Ultra 2 UltraSPARC-II Module X-Option—March 1997...
  • Page 5 Nippon — Japan Electromagnetic Compatibility...
  • Page 6 Sun Ultra 2 UltraSPARC-II Module X-Option—March 1997...

  • Page 7: Table Of Contents

    Contents Electromagnetic Compatibility......1. UltraSPARC-II Module X-Option ..... . . 1.1 System Software Requirements .
  • Page 8 6.5 EnergyStar ........viii Sun Ultra 2 UltraSPARC-II Module X-Option—March 1997...

  • Page 9: Ultrasparc-Ii Module X-Option

    UltraSPARC-II Module X-Option ™ This book contains procedures for installing an UltraSPARC -II module ™ ™ x-option in a Sun Ultra 2 system. Figure 1-1 Ultra 2 System...

  • Page 10: System Software Requirements

    MHz) of the UltraSPARC module(s) installed. 1.3 SCD Compliance Sun Ultra 2 systems have been independently tested and verified to comply with revision 2.1 of the SPARC Compliance Definition (SCD) developed by SPARC International, Inc. These systems are binary compatible with all other systems and software that conform to SCD version 2.1.

  • Page 11: Ultrasparc-Ii Module X-Option Kit

    1.6 Using This Book This book shows you how to install and test UltraSPARC-II modules in Ultra 2 systems. The procedures are arranged in a sequence of four chapters. Read and perform the procedures in the remainder of this book in sequence, starting with Chapter 2, “Opening the System Unit,”...
  • Page 12 Sun Ultra 2 UltraSPARC-II Module X-Option—March 1997...

  • Page 13: Opening The System Unit

    Opening the System Unit This chapter contains the following sections: • Removing Power from the System • Removing the System Unit Cover • Attaching the Wrist Strap 2.1 Removing Power from the System Before turning off system power, shut down the operating system to avoid loss of data.
  • Page 14 Standby Switch When the power is off, the LED on the middle front of the system is not lit and the fans are not running (Figure 2-2). Figure 2-2 Front Panel LED Location Sun Ultra 2 UltraSPARC-II Module X-Option—March 1997...

  • Page 15: Removing The System Unit Cover

    Caution – When the Power On/Standby switch is pressed and the AC power cord remains connected to a power outlet, hazardous AC voltage is still present in the power supply primary. 6. Detach all cords and cables connected to the system unit except for the AC power cord.
  • Page 16 Figure 2-4 Lifting the Top Cover 3. Lift the top cover so that it clears the chassis, and push the cover forward so that it clears the chassis (Figure 2-4). Sun Ultra 2 UltraSPARC-II Module X-Option—March 1997...

  • Page 17: Attaching The Wrist Strap

    2.3 Attaching the Wrist Strap Attach end to metal casing of power supply Wrap the wrist strap twice around your wrist (adhesive against your skin). Figure 2-5 Attaching the Wrist Strap Opening the System Unit...
  • Page 18 1. Unwrap the first two folds of the wrist strap and wrap the adhesive side firmly around your wrist (Figure 2-5). 2. Attach the adhesive copper strip to the metal casing of the power supply inside your system (Figure 2-6). Sun Ultra 2 UltraSPARC-II Module X-Option—March 1997...

  • Page 19: Updating The Flash Prom

    Updating the Flash PROM Use the flash PROM update CD-ROM and the accompanying programming guide to update your system flash PROM to OpenBoot PROM version 3.7 (or later). Note – If you do not have OpenBoot PROM version 3.7 (or later) installed in your system and do not have the flash PROM update utility software containing version 3.7 (or later), you must obtain the software from SunService or another authorized service provider.
  • Page 20 Sun Ultra 2 UltraSPARC-II Module X-Option—March 1997...

  • Page 21: Removing The Ultrasparc Module

    Removing the UltraSPARC Module Read this chapter if: • Your system is equipped with one UltraSPARC module and you are replacing the module • Your system is equipped with one UltraSPARC module and you are replacing the module with two new modules •...
  • Page 22 Slot 0 Slot 1 Figure 4-1 UltraSPARC Module Locations and Shroud-Assembly Processor Area Sun Ultra 2 UltraSPARC-II Module X-Option—March 1997...
  • Page 23 90-degrees 90-degrees 135-degrees 135-degrees Figure 4-2 Removing the UltraSPARC Module 1. Grip the sides of the shroud-assembly processor area (Figure 4-1). 2. With the thumbs of both hands, simultaneously lift the two levers on the module upwards and to the side (about 135-degrees) (Figure 4-2). 3.
  • Page 24 Sun Ultra 2 UltraSPARC-II Module X-Option—March 1997...

  • Page 25: Installing The Ultrasparc Module

    Installing the UltraSPARC Module Slot 0 Slot 1 Figure 5-1 Ultra 2 Processor Slot Locations 1. Unpack the processor module. 2. Place the module on an antistatic surface. 3. Identify the appropriate or available slot (Figure 5-1).
  • Page 26 135-degrees 135-degrees Figure 5-2 Lowering the Module Into the Chassis 6. Lower the module along the vertical plastic guides until the module touches the slot socket on the main logic board (Figure 5-2). Sun Ultra 2 UltraSPARC-II Module X-Option—March 1997...
  • Page 27 7. With both hands, simultaneously turn and press the levers downward to the fully horizontal position. Firmly press the module downward into the socket until it is fully seated and the levers are fully locked (Figure 5-3). Figure 5-3 Locking the Module in Place Installing the UltraSPARC Module...
  • Page 28 Sun Ultra 2 UltraSPARC-II Module X-Option—March 1997...

  • Page 29: Completing The Installation

    Completing the Installation 5.1 Changing the Clocking Select Jumper • Table 6-1 gives information about the clocking select jumper functionality. • Figure 6-1 shows the location of the clocking select jumper on the main logic board. • Figure 6-2 shows the two available jumper settings. Table 5-1 UltraSPARC Module Clocking Select Jumper Settings Default Jumper on...
  • Page 30 Back Panel Power Supply J3002 Main Logic Board (MLB) J2301 CPU — 0 J2801 CPU — 1 J2901 Speaker Front Panel Figure 5-1 Clocking Select Jumper Location on Main Logic Board UltraSPARC-II Module X-Option—March 1997...

  • Page 31: Closing The System Unit

    Pin 1 Pin 2 Pin 3 J2301 Default jumper position, UltraSPARC-I modules, 168 MHz and 200 MHz J2301 Jumper position, UltraSPARC-II modules, 300 MHz J2301 Figure 5-2 Clocking Select Jumper Positions To change the jumper: Use needlenose pliers to remove the jumper from position A and to install the jumper at position B (Figure 6-2).
  • Page 32 Figure 5-3 Lowering the Cover Onto the System Unit Back Panel 4. Guide the two top cover plastic tabs in place onto the back panel. You will hear a click as each tab seats with the back panel (Figure 6-4). 5.

  • Page 33: Turning On The Power

    Figure 5-5 Power On/Standby Switch 5.4 Power-On Self-Test (POST) For a full description of the Power-On Self-Test (POST), refer to the Sun Ultra 2 Service Manual. 5.5 EnergyStar If you experience RED State Exception failures when exercising EnergyStar suspend/resume functions, install patch 104729-01.
  • Page 34 UltraSPARC-II Module X-Option—March 1997...
