Note: The camera will reserve the 10.11.22.32/28 subnet for internal use while the USB Wi-Fi
Adapter is plugged in.

Assigning an IP Address

The device automatically obtains an IP address when it is connected to a network.
Note: If the device cannot obtain an IP address from a DHCP server, it will use Zero Configuration
Networking (Zeroconf) to choose an IP address. When set using Zeroconf, the IP address is in the
169.254.0.0/16 subnet.
The IP address settings can be changed using one of the following methods:
The mobile web interface using the USB Wifi Adapter. For more information, see
l
USB Wi-Fi Adapter on the previous
Device's web browser interface: http://<camera IP address>/.
l
Network Video Management software application (for example, the Avigilon Control Center™
l
software).
ARP/Ping method. For more information, see
l
page 18.
Note: The default device username is administrator with no password.
Accessing the Live Video Stream
Live video stream can be viewed using one of the following methods:
The mobile web interface using the USB Wifi Adapter. For more information, see
l
USB Wi-Fi Adapter on the previous
Web browser interface: http://< camera IP address>/.
l
Network Video Management software application (for example, the Avigilon Control Center
l
software).
Note: The default device username is administrator with no password.

Aiming the Camera

Reference the camera's live stream as you aim the camera.
Assigning an IP Address
page.
Setting the IP Address Using the ARP/Ping Method on
page.
(Optional) Using the
(Optional) Using the
11
