After you connect to the Wi-Fi signal broadcast by the adapter, you can access the mobile web interface
from any mobile device using the following address:
http://camera.lan
For more information about configuring the camera from the mobile web interface see Avigilon USB Wi-Fi
Adapter System User Guide.
Note: The camera will reserve the 10.11.22.32/28 subnet for internal use while the USB Wi-Fi
Adapter is plugged in.

Assigning an IP Address

The device automatically obtains an IP address when it is connected to a network.
Note: If the device cannot obtain an IP address from a DHCP server, it will use Zero Configuration
Networking (Zeroconf) to choose an IP address. When set using Zeroconf, the IP address is in the
169.254.0.0/16 subnet.
The IP address settings can be changed using one of the following methods:
The mobile web interface using the USB Wifi Adapter. For more information, see
l
USB Wi-Fi Adapter on the previous
Device's web browser interface: http://<camera IP address>/.
l
Network Video Management software application (for example, the Avigilon Control Center™
l
software).
ARP/Ping method. For more information, see
l
page 22.
Note:
Depending on the manufacture date of your camera, you will have one of the two options below to
log in for the first time:
Cameras manufactured after January 1, 2020: these cameras do not have a default username
l
or password and will be in a factory default state. You must create a user with administrator
privileges before the camera is operational. For more information, see
Username and Password on the previous
Cameras manufactured before January 1, 2020: login to the camera using the default
l
username of administrator with no password. It is recommended that you change the
password after your first login.
Assigning an IP Address
page.
Setting the IP Address Using the ARP/Ping Method on
page.
(Optional) Using the
Initializing a Camera
